ABB - Electrification S203MUC-B25 - All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution.
ABB - Electrification

S203MUC-B25

Contact for Pricing

Overview

The ABB System pro M compact S203MUC-B25 is a 3-pole accessory designed for System pro M compact electrical distribution systems. This accessory supports a rated cross-section of 25 mm² and a rated operational current of 65 A, making it suitable for MS116, MS132, and MO132 circuit breakers. With a compact design weighing just 0.042 kg per piece, it is optimized for space-efficient installations while maintaining high reliability. Engineered for UL/CSA Type E/F and IEC mounting forms, the S 200 M UC ensures compatibility with global electrical standards. Its modular design allows for quick assembly and disassembly, reducing installation and maintenance downtime. The accessory is ideal for industrial, commercial, and infrastructure projects where efficient electrical distribution is critical. Key applications include warehousing, project engineering, and routine maintenance of electrical systems. The S 200 M UC accessory integrates seamlessly with the ABB System pro M compact ecosystem, providing a flexible solution for both new installations and system upgrades. Its lightweight yet durable construction ensures long-term performance in high-demand environments. ABB’s System pro M compact range is trusted for its precision engineering and adherence to international standards. The S 200 M UC accessory is no exception, offering consistent performance with minimal maintenance requirements. Whether used in high-capacity distribution panels or compact control systems, this accessory delivers the reliability and compatibility needed for modern electrical infrastructure. Specifications: SKU: S203MUC-B25, Manufacturer: ABB - Electrification, Rated Cross Section: 25 mm², Rated Operational Current: 65 A, Suitable for: MS116, MS132, MO132, Mounting Form: UL/CSA Type E/F and IEC, Weight (1 pce): 0.042 kg, UNSPSC Code: 39121603, Country of Origin: US.
  • ABB System pro M compact S203MUC-B25 3-pole accessory
  • Supports 25 mm² rated cross-section
  • Rated operational current of 65 A
  • Compatible with MS116, MS132, and MO132 circuit breakers
  • UL/CSA Type E/F and IEC mounting form compatibility

Specifications

Amperage Rating, Maximum
25 A
Amperage Rating, Minimum
25 A
Application
Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
Current Rating
65 A
Interrupt Rating
(500 V DC) 10 kA / (480Y / 277 V AC) 6 kA
Mounting Type
UL/CSA Type E/F and IEC mounting forms
Number of Poles
3
Poles
3-pole
Series
System pro M compact S 200 M UC
Size
82x110x108mm
Special Features
The miniature circuit breaker S 200 M UC extends the establishedABB System pro M compact® product range with an MCB for DC and AC applications. The S 200 M UC impresses with its performance range and the accordingly large amount of approvals. Its high inbuilt short circuit breaking capacity across theentire model line, its flexible AC and DC application and its approval and compliance in accordance with all major international and local standards make it truly unique.All current System pro M compact® accessories can be combined easily with the new model line. Whether warehousing or project engineering, planning, installing or maintaining your equipment, the S 200 M UC is a simple and flexible solution.
Standard
IEC/EN 60898-1 / IEC/EN 60947-2
Tripping Characteristic
B
Type
Contactors
Voltage Rating
(500 V DC) / (480Y / 277 V AC)
Package Dimensions (L x W x H)
2.28 IN x 3.62 IN x 3.15 IN
Package Dimensions (L x W x H)
5.7912 cm x 9.1948 cm x 8.001 cm
Package Weight (Imperial)
0.880 L
Package Weight (Metric)
0.399 kg
