Overview
- 2-phase, 12-pole DIN rail busbar
- Current Rating: 80/115 A
- Length: 208.8 mm
- 16 mm² terminals for MCB connection
- DIN rail mounting for easy installation
- Busbar Length: 208.8mm
- Designed for 35mm DIN Rail Mounting
- BCPD (Busbar Connection) for simplified MCB connections
Specifications
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Connection Type | DIN Rail / MCB Connections |
Connection Type | Busbar Connection |
Current Rating | 80/115 A |
Current Rating | 80 A |
Material | Metal |
Mounting Type | 35 mm DIN Rail |
Mounting Type | DIN Rail Mount |
Mounting Type | DIN Rail |
Poles | 12P |
Poles | 12 |
Series | PS2 |
Series | PS...BP-C |
Size | 25mm² |
Size | 82x110x108mm |
Size | 208.8 mm length, 25 mm² cross-section |
Size | 208.8 mm |
Special Features | Terminal type: Screw terminals |
Standard | RoHs, CSA, cUL, CE, GOST |
Type | Contactors |
Package Dimensions (L x W x H) | 9.84 IN x 9.25 IN x 6.69 IN |
Package Dimensions (L x W x H) | 24.9936 cm x 23.495 cm x 16.9926 cm |
Package Weight (Imperial) | 15.040 L |
Package Weight (Metric) | 6.822 kg |
Frequently Asked Questions
What is the amp rating for the ABB PS2/12/16BP busbar?
The ABB PS2/12/16BP busbar has an amp rating of 80/115A.
How many poles does the ABB PS2/12/16BP busbar have?
The ABB PS2/12/16BP busbar features 12 poles.
What is the length of the ABB PS2/12/16BP busbar?
The busbar length for the ABB PS2/12/16BP is 208.8mm.
Is the ABB PS2/12/16BP busbar compatible with DIN rail mounting?
Yes, the ABB PS2/12/16BP busbar is designed for mounting on a standard 35mm DIN rail.
What type of electrical system is the ABB PS2/12/16BP busbar for?
The ABB PS2/12/16BP busbar is designed for 2-phase electrical systems.
Which ABB MCB series are compatible with the PS2/12/16BP busbar?
The PS2/12/16BP busbar is compatible with ABB MCB series SU200M, SU200ML, SUP200M, and S200UDC.
How to Install the ABB PS2/12/16BP Busbar
Step-by-step guide for mounting and wiring the ABB PS2/12/16BP busbar on a DIN rail.
Estimated time: 15m
Tools needed:
Screwdriver, DIN rail
Supplies needed:
Mounting screws (if required)
- Position the busbar on the DIN rail
Align the PS2/12/16BP busbar with the DIN rail and snap it into place.
- Secure the busbar
Use mounting screws (if provided) to secure the busbar to the DIN rail for stability.
- Connect the MCBs
Attach the compatible ABB MCBs (SU200M, SU200ML, etc.) to the busbar terminals, ensuring proper phase alignment.
- Verify connections
Double-check all connections for tightness and correct polarity before energizing the panel.
