Contact for Pricing
Overview
- 18-pole single-phase busbar for circuit protection distribution
- 80A current rating for reliable power handling
- DIN rail mounting for easy installation
- Supports ring lug and feeder terminal connections
- Compliant with UL 508, IEC EN 60947-1, cULus, CE, and RoHS standards
- Light gray (RAL 7035) housing
- Optional mounting positions
- cULus listed, CE/RoHS compliant
Specifications
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Color | Light Gray (RAL 7035) |
Connection Type | Ring lug or feeder terminal |
Connection Type | Ring Lug / Feeder Terminal |
Connection Type | Cable with Ring Lug / Feeder Terminal |
Connection Type | Cable with ring lug or feeder terminal |
Connection Type | Busbar |
Current Rating | 80 A |
Material | Metal (busbar) |
Material | Plastic (Housing) |
Mounting Type | DIN Rail Mount |
Mounting Type | DIN Rail |
Poles | 18 |
Poles | 18P |
Poles | 1P |
Poles | 18 poles |
Series | PS1 |
Series | SYSTEM PRO M COMPACT™ |
Size | 25 mm² |
Size | 82x110x108mm |
Size | 18-pole |
Size | 25 mm² cross-section |
Special Features | Terminal type: Screw terminals |
Standard | RoHs, CSA, cUL, CE, GOST |
Type | Contactors |
Package Dimensions (L x W x H) | 11.81 IN x 8.86 IN x 4.92 IN |
Package Dimensions (L x W x H) | 29.9974 cm x 22.5044 cm x 12.4968 cm |
Package Weight (Imperial) | 0.950 L |
Package Weight (Metric) | 0.431 kg |
HB32430
ADP, 25A, 45X200, 1 DIN, Bulletin HB2 (Busbar Components), Size/Dims: 45x200x63mm, Material/Finish:
