Overview
- 2-pole + neutral (2P+N+G) surge protection for split-phase networks
- 40 kA maximum discharge current (Imax) and 440 V AC MCOV
- Type 1 SPD, UL 1449 4th Edition compliant for Type 2 applications
- Replaceable and pluggable MOV cartridges with state indicator flag
- DIN rail mounting for easy installation, 200 kAIC fault rating
Specifications
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Connection Type | Standard electrical panel integration |
Current Rating | 40 kA |
Mounting Type | Panel Mount |
Poles | 2P+N |
Series | OVR SPD |
Size | 82x110x108mm |
Special Features | Terminal type: Screw terminals |
Standard | RoHs, CSA, cUL, CE, GOST |
Type | Contactors |
Voltage Rating | 440 V |
Voltage Rating | 440 VAC |
Package Dimensions (L x W x H) | 2.4 IN x 4.61 IN x 3.23 IN |
Package Dimensions (L x W x H) | 6.096 cm x 11.7094 cm x 8.2042 cm |
Package Weight (Imperial) | 1.000 L |
Package Weight (Metric) | 0.454 kg |
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What is the maximum discharge current of this ABB surge protector?
The ABB OVRT22N40440PTSU has a maximum discharge current of 40 kA.
What is the maximum continuous operating voltage (MCOV) for the OVRT22N40440PTSU?
The maximum continuous operating voltage (MCOV) for this device is 440 V AC.
What type of network is this surge protector designed for?
This surge protector is designed for split-phase 2w+N+Gnd networks.
Does this ABB SPD have replaceable cartridges?
Yes, the ABB OVRT22N40440PTSU features replaceable and pluggable cartridges.
How is the OVRT22N40440PTSU mounted?
The device is designed for DIN rail mounting.
What is the Voltage Protection Rating (VPR) for this surge protector?
The Voltage Protection Rating (VPR) for the OVRT22N40440PTSU is 1.4 kV.
What is the fault rating (SCCR) of the OVRT22N40440PTSU?
The fault rating (SCCR) for this surge protector is 200 kAIC, and it requires upstream protection.
What is the operating temperature range for this ABB surge device?
The device operates within a temperature range of -40° to 80°C.
How to Install the ABB OVRT22N40440PTSU Surge Protector
Step-by-step guide for installing the ABB OVRT22N40440PTSU surge protector on a DIN rail.
Estimated time: 15m
Tools needed:
Phillips head screwdriver, Wire stripper, Wire cutter
Supplies needed:
Appropriate gauge wire (AWG #6-14 stranded/solid), DIN rail
- Prepare the DIN Rail
Ensure a standard 35mm DIN rail is securely mounted in the electrical panel at the desired location.
- Connect the Surge Protector
Connect the incoming power conductors (L, N, G) to the corresponding terminals on the surge protector. Ensure proper wire stripping and secure connections using a screwdriver. Refer to the device's terminal markings for correct polarity.
- Mount the Device
Align the mounting clip on the back of the OVRT22N40440PTSU with the DIN rail and firmly push down until it snaps into place. Ensure the device is securely attached to the rail.
- Verify Installation
Visually inspect all connections to ensure they are tight and correct. Check the cartridge state indicator flag to confirm the device is operational. Ensure upstream protection (breaker/fuse) is correctly installed.
