Overview
- Expands ABB OS Mini fusible disconnect switches with up to 6 auxiliary contacts.
- Designed for left-side mounting on compatible ABB OS Mini disconnect switch series.
- Lightweight component with a unit weight of 0.06 kg.
- Enhances control and signaling capabilities for electrical distribution equipment.
- Manufactured by ABB Electrification for reliable performance.
Specifications
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Connection Type | Modular/Plug-in |
Connection Type | Snap-on |
IP Rating | IP20 |
Material | Metal |
Material | Plastic/Metal (implied) |
Material | Plastic/Composite |
Mounting Type | Snap-on, tool-free |
Mounting Type | Left side of switch |
Mounting Type | Left-side Mount |
Mounting Type | Left mount |
Mounting Type | Snap-on, tool-free installation on left side of OS30F switch |
Mounting Type | Left-side mounting |
Mounting Type | Left-Mount |
Mounting Type | snap-on |
Mounting Type | Tool-free left side mounting |
Mounting Type | Left-side |
Mounting Type | Left Side Mount |
Poles | up to six auxiliary contact blocks or fuse monitors |
Poles | Up to 6 auxiliary contact blocks or fuse monitors |
Poles | Up to 6 contacts |
Poles | NO (Normally Open) with positive opening |
Poles | 6 contacts |
Poles | up to 6 |
Poles | NO (Normally Open) Contacts |
Poles | 6-pole |
Poles | 6 |
Series | OS Mini (OS30F) |
Series | OS Mini |
Series | OSZ4 |
Series | ABB OS Mini |
Size | 82x110x108mm |
Size | 0.06 kg |
Special Features | OSZ4 AUX.CONTACT FRAME |
Standard | RoHs, CSA, cUL, CE, GOST |
Type | Contactors |
Package Dimensions (L x W x H) | 3.937 IN x 1.969 IN x 1.969 IN |
Package Dimensions (L x W x H) | 10 cm x 5.0013 cm x 5.0013 cm |
Package Weight (Imperial) | 0.132 L |
Package Weight (Metric) | 0.060 kg |
Frequently Asked Questions
What is the protection rating of the OSZ4 frame?
The OSZ4 frame provides IP20 protection for installed auxiliary contacts.
Where is the OSZ4 frame mounted?
The OSZ4 frame is mounted on the left side of the OS Mini (OS30F) fusible disconnect switch.
What is the manufacturer of the OSZ4 frame?
The OSZ4 frame is manufactured by ABB Electrification in Germany.
What is the order number for the OSZ4 frame?
The order number for the OSZ4 frame is 1SCA022530R0200.
What is the maximum number of auxiliary contacts supported?
The OSZ4 frame supports up to six auxiliary contact blocks or fuse monitors.
Is the OSZ4 frame compatible with gold-plated contacts?
Yes, gold-plated variants (OA1G10AU, OA3G01AU) are compatible for harsh environments and low-voltage applications.
Can the OSZ4 frame be used with fuse monitors?
Yes, the OSZ4 frame supports fuse monitors in addition to auxiliary contact blocks.
What is the positive opening feature on NO contacts?
The positive opening function ensures reliable circuit interruption in NO contacts.
How to Mount the ABB OSZ4 Auxiliary Contact Frame
Step-by-step guide for installing the OSZ4 frame onto an ABB OS Mini disconnect switch.
Estimated time: 15m
Tools needed:
Screwdriver
Supplies needed:
ABB OSZ4 Auxiliary Contact Frame, ABB OS Mini Disconnect Switch, ABB Auxiliary Contact Blocks (e.g., OA1G10, OA3G01)
- Prepare the OS Mini disconnect switch
Ensure the OS Mini disconnect switch is de-energized and safely isolated.
- Attach the OSZ4 frame
Align the OSZ4 auxiliary contact frame with the designated mounting points on the left side of the OS Mini disconnect switch. Secure the frame using appropriate screws.
- Install auxiliary contact blocks
Snap the desired ABB auxiliary contact blocks (e.g., OA1G10, OA3G01) into the OSZ4 frame. Ensure they are securely seated.
- Connect wiring
Wire the auxiliary contacts according to your system's signaling and monitoring requirements. Refer to the auxiliary contact block's documentation for specific wiring diagrams.
- Verify installation
Double-check all connections and ensure the frame and contact blocks are firmly attached before re-energizing the system.
