Overview

The ABB OS100GJ12 is a UL/CSA-listed Class J fusible disconnect switch designed for industrial power distribution and motor control circuits. This 3-pole, 100A front-operated switch fuse provides reliable overcurrent protection and manual circuit isolation in demanding environments. Rated for 480V AC, it features clamp terminals for secure connections and a compact design with the operating mechanism positioned between the poles (designated by '12' in the SKU), optimizing panel space usage. The OS100GJ12 is manufactured in the USA and meets stringent UL/CSA standards for electrical safety and performance. Note: Handle and shaft are sold separately for customization. Typical applications include motor control centers, power distribution panels, industrial machinery, and commercial electrical systems where Class J fuse protection is required. The double-break contact system ensures safe upstream and downstream circuit interruption, while the front operation allows for easy access in densely populated enclosures. Compatible with Class J fuses (100A rating), this switch fuse delivers interrupting ratings suitable for high-fault applications. The clamp terminal design accepts AWG 14-4 cable sizes, providing flexibility for various wiring configurations. UL 98 compliant, this product is ideal for applications requiring reliable fault isolation and maintenance safety.
  • 3-pole Class J fusible disconnect switch rated 100A at 480V AC
  • Front-operated design with mechanism between poles for compact installation
  • UL/CSA-listed with clamp terminals for secure AWG 14-4 cable connections
  • Double-break contact system for safe upstream/downstream circuit interruption
  • Manufactured in USA; handle and shaft sold separately for customization

Specifications

Application
Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
Size
82x110x108mm
Special Features
Switch Fuses,Front Operated,3-pole,12 (Between the Poles),Class J,100 A,Handle and shaft not included,
Standard
RoHs, CSA, cUL, CE, GOST
Type
Contactors
Package Dimensions (L x W x H)
9.528 IN x 7.559 IN x 6.26 IN
Package Dimensions (L x W x H)
24.2011 cm x 19.1999 cm x 15.9004 cm
Package Weight (Imperial)
4.530 L
Package Weight (Metric)
2.055 kg

Similar Products

OS100GJ03

Current Rating: 100 A

Poles: 3-pole

Mounting Type: Front Operated, Left Side

OS100GJ30

OS1200L03

Current Rating: 1200 A

Poles: 3

Mounting Type: Front Operated, Left Side

OS1200L30-FC

Voltage Rating: 690 V AC/DC

Current Rating: 1200 A

Material: Copper

OS30FAJ12

OS30FAJ12P

Special Features: Terminal type: Screw terminals

Current Rating: 30 A

Poles: 3P

You May Also Be Interested In

6-pole, front operated, base mounted, DIN-rail mountable switch-diconnector / non-fusible diconnect switch with front protected clamp terminals, handle and shaft are not included

OT100F6

3-pole, front operated, door mounted, switch-diconnector / non-fusible diconnect switch with front protected clamp terminals, handle and shaft are not included

OT100FT3

3-pole, front operated, base mounted switch-diconnector with protected clamp terminals, handle and shaft are not included
