Contact for Pricing
Overview
- Max 6 auxiliary contacts, 16A (Ith) rating
- Compatible with ABB EOT520–EOT580, EOT930–EOT9100, EOT9200–EOT9600 series
- Left-side mounting with screw terminals for 2.5 mm² cables
- Durable plastic construction, 0.06 kg weight
- Enables status feedback and remote monitoring in switchgear
- Weight: 0.06 kg
- Manufactured in Germany
Specifications
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Connection Type | Screw Terminal (2.5 mm²) |
Connection Type | Screw Terminal (up to 2 x 2.5 mm²) |
Connection Type | Screw Mount |
Connection Type | Screw Terminal |
Current Rating | 16 A |
Material | Metal |
Material | Plastic/Composite |
Material | Plastic |
Material | Steel |
Mounting Type | Flexible mounting (up to 8 blocks on left side for EOT9200–EOT9600 series, 2 blocks per side for other series) |
Mounting Type | Mounts on compatible ABB operating mechanisms |
Mounting Type | Screw-mount |
Mounting Type | Side Mount (varies by series) |
Mounting Type | Side mounting on disconnect switches |
Mounting Type | Flexible mounting (up to 8 blocks on left side for EOT9200–EOT9600, 2 blocks per side for others) |
Mounting Type | Left-side mounting |
Mounting Type | Left side mounting for EOT9200–EOT9600 series, 2 blocks per side for other series |
Mounting Type | Side-mounted |
Mounting Type | Screw Mounting |
Mounting Type | Screw Mount |
Mounting Type | Side Mounting |
Mounting Type | Left-side mount (up to 8 blocks for EOT9200–EOT9600 series, 2 blocks per side for others) |
Poles | 6 contacts |
Poles | 2 blocks (NO/NC) |
Poles | 2 (NO+NC) |
Poles | Up to 2 blocks (EOT520/EOT580/EOT930/EOT9100) or 8 blocks (EOT9200/EOT9600) |
Poles | Up to 8 contacts |
Poles | 2 (NO/NC) |
Poles | 2 (EOT520/580/930/9100), 8 (EOT9200/9600) |
Poles | 2 auxiliary contact blocks (EOT520/580/930/9100), up to 8 (EOT9200/9600) |
Poles | Up to 2 (EOT520/580/930/9100) or 8 (EOT9200/9600) |
Poles | 2 or 8 (depending on series) |
Poles | NO/NC |
Poles | 6 |
Series | EOT520-EOT580, EOT930-EOT9100, EOT9200-EOT9600 |
Series | EOT520, EOT580, EOT930, EOT9100, EOT9200, EOT9600 |
Series | OEA28 |
Series | EOT520–EOT580, EOT930–EOT9100, EOT9200–EOT9600 |
Size | 0.06 kg |
Size | 82x110x108mm |
Special Features | OEA28 MODULE FOR AUX.CONTACTS |
Standard | RoHs, CSA, cUL, CE, GOST |
Type | Contactors |
Package Dimensions (L x W x H) | 2.756 IN x 3.937 IN x 0.787 IN |
Package Dimensions (L x W x H) | 7.0002 cm x 10 cm x 1.999 cm |
Package Weight (Imperial) | 0.143 L |
Package Weight (Metric) | 0.065 kg |
SPAS240AB8DR
Auxiliary switches provide remote indication of whether the circuit breaker main contacts are opened or closed via open or closed SPDT elements. AB8DRSPAS600AB4R
Auxiliary switches provide remote indication of whether the circuit breaker main contacts are opened or closed via open or closed SPDT elements. 0AB4R
Frequently Asked Questions
What is the current rating for the auxiliary contact blocks?
The auxiliary contact blocks (OA1G10 for NO, OA3G01 for NC) have a thermal current (Ith) rating of 16 A.
What cable cross-section can be used with the auxiliary contacts?
The auxiliary contact blocks support cable cross-sections up to 2 x 2.5 mm².
What is early-break functionality?
Early-break functionality means that the Normally Open (NO) auxiliary contacts break before the main switch contacts open.
Which ABB disconnect switch series are compatible with the OEA28 module?
The OEA28 module is compatible with ABB disconnect switch series EOT520–EOT580, EOT930–EOT9100, and EOT9200–EOT9600.
How many auxiliary contact blocks can be mounted on EOT9200–EOT9600 switches?
Up to 8 auxiliary contact blocks can be mounted on the left side of EOT9200–EOT9600 series switches using the OEA28 module.
How many auxiliary contact blocks can be mounted on EOT520–EOT580 switches?
Up to 2 auxiliary contact blocks can be mounted on each side (left or right) of EOT520–EOT580 series switches.
Are gold-plated auxiliary contact blocks available?
Yes, gold-plated versions (indicated by AU1 in the order number) are available for extremely difficult circumstances and low voltages.
