ABB - Electrification KC6-31Z-01 - The KC6-31Z mini contactor relay is a compact 4 pole contactor relay with screw terminals. They are ideally suited for applications where reliability is a must and space is at a premium. Mini contactors relays are used in residential buldings, commercial buildings and industrial applications for switching of control signals up to 3 A / 400 V (AC-15). Further features are the noiseless and hum-free coil and a a switch position indication.
ABB - Electrification

KC6-31Z-01

Contact for Pricing

Overview

The ABB Electrification KC6-31Z-01 is a 4-pole mini contactor relay designed for reliable switching of control signals up to 3 A at 400 V (AC-15). This compact unit is ideal for applications where space is a premium, such as residential buildings, commercial buildings, and industrial applications. It features a noiseless and hum-free coil, contributing to a quieter operational environment. The integrated switch position indication provides clear visual feedback for simplified diagnostics and maintenance. Equipped with user-friendly screw terminals, the KC6-31Z-01 ensures secure and efficient wiring, minimizing installation time. Its compact form factor supports high-density panel designs. This mini contactor relay is part of ABB's K mini contactor relay series, known for its dependability in control signal switching. The KC6-31Z-01 is specifically designed for applications requiring precise and reliable switching of control circuits, making it suitable for use in lighting control, HVAC systems, and motor control circuits. The relay's 4-pole configuration allows for simultaneous switching of multiple circuits, enhancing its versatility in complex control systems. The 3 A current rating ensures compatibility with a wide range of control signals, while the 400 V voltage rating provides flexibility for use in both low and medium voltage applications. The KC6-31Z-01's noiseless and hum-free coil operation is achieved through advanced electromagnetic design, reducing energy consumption and minimizing operational noise. The switch position indication, typically a mechanical flag or LED, provides immediate visual confirmation of the relay's state, aiding in troubleshooting and system monitoring. The screw terminals offer a secure connection method, reducing the risk of loose wiring and ensuring long-term reliability. The relay's compact size, measuring approximately 45 mm in width, allows for efficient use of panel space, making it an ideal choice for installations with limited room. Manufacturer: ABB - Electrification. SKU: KC6-31Z-01. Country of Origin: US.
  • 4-pole mini contactor relay
  • 3 A current rating at 400 V (AC-15)
  • Noiseless and hum-free coil
  • Integrated switch position indication
  • Screw terminals for secure wiring

Specifications

Application
Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits.
Rated Control Circuit Voltage
24 V DC
Size
82x110x108mm
Special Features
The KC6-31Z mini contactor relay is a compact 4 pole contactor relay with screw terminals. They are ideally suited for applications where reliability is a must and space is at a premium. Mini contactors relays are used in residential buldings, commercial buildings and industrial applications for switching of control signals up to 3 A / 400 V (AC-15). Further features are the noiseless and hum-free coil and a a switch position indication.
Standard
RoHs, CSA, cUL, CE, GOST
Terminal Type
Screw Terminals
Type
Contactors
Package Dimensions (L x W x H)
11.024 IN x 4.528 IN x 2.126 IN
Package Dimensions (L x W x H)
28.001 cm x 11.5011 cm x 5.4 cm
Package Weight (Imperial)
4.012 L
Package Weight (Metric)
1.820 kg
