Overview
- 4-pole vertical DIN rail connector rated for 60A continuous current
- Mounts on 35 mm DIN rail per EN/IEC 60715 standards
- Supports auxiliary contact configurations: 2NC, 3NC, or 4NC
- Compatible with ABB XT2V125 + TM60 circuit breakers and RK5/J fuses up to 60A
- Manufactured in Germany for industrial-grade reliability
Specifications
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Current Rating | 60 A |
Material | Industrial-grade materials |
Material | Plastic |
Mounting Type | 35 mm DIN rail, EN/IEC 60715 |
Mounting Type | Vertical DIN rail mount (EN/IEC 60715) |
Mounting Type | Vertical DIN rail |
Mounting Type | 35 mm DIN Rail |
Poles | 4 |
Poles | 4-Pole |
Poles | 4P |
Series | XT4 |
Size | 35 mm DIN rail |
Size | 82x110x108mm |
Size | 35 mm DIN rail mount |
Special Features | Terminal type: Screw terminals |
Standard | RoHs, CSA, cUL, CE, GOST |
Type | Contactors |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 0.160 L |
Package Weight (Metric) | 0.073 kg |
Frequently Asked Questions
What is the current rating of the BEA140/XT4?
The BEA140/XT4 has a current rating of 60A.
How many poles does the BEA140/XT4 have?
The BEA140/XT4 is a 4-pole connector.
What type of DIN rail does the BEA140/XT4 mount on?
The BEA140/XT4 mounts on a 35 mm DIN rail per EN/IEC 60715 standards.
Is the BEA140/XT4 compatible with XT2V125 circuit breakers?
Yes, the BEA140/XT4 is compatible with XT2V125 + TM60 circuit breakers.
What fuse types are compatible with the BEA140/XT4?
The BEA140/XT4 is compatible with fuses up to 60A, including RK5/J types.
Does the BEA140/XT4 support auxiliary contacts?
Yes, the BEA140/XT4 supports 2NC, 3NC, or 4NC auxiliary contacts for flexible control.
Where is the BEA140/XT4 manufactured?
The BEA140/XT4 is manufactured in Germany.
What applications is the BEA140/XT4 suitable for?
The BEA140/XT4 is suitable for motor protection, control panels, and industrial automation systems.
How to Install the ABB BEA140/XT4 Vertical DIN Rail Connector
Step-by-step guide to mounting and wiring the BEA140/XT4 connector.
Estimated time: 15m
Tools needed:
Screwdriver, Wire strippers, Crimping tool
Supplies needed:
Mounting screws, Wiring cables, Ferrules (if required)
- Mount the connector to the DIN rail
Position the BEA140/XT4 vertically on a 35 mm DIN rail per EN/IEC 60715 standards. Ensure it is securely latched in place.
- Connect the main power cables
Strip the insulation from the power cables to the required length. Insert the cables into the appropriate terminals and tighten the screws to the specified torque.
- Connect auxiliary contacts (if used)
For 2NC, 3NC, or 4NC auxiliary contacts, connect the control wires to the designated terminals. Ensure proper polarity and secure connections.
- Verify connections and secure the device
Double-check all connections for tightness and proper alignment. Ensure the connector is firmly mounted and no loose wires are present.
