ABB - Electrification AF205-30-11-12 - A 3-phase Contactor suitable for various applications such as Motor starting, Isolation, By-pass and Distribution application up to max 1000 V. Operated with wide control voltage range 48-130 V, 50/60 Hz and DC
ABB - Electrification

AF205-30-11-12

Contact for Pricing

Overview

The ABB AF205-30-11-12 3-phase contactor is a robust industrial solution designed for motor starting, isolation, bypass, and distribution applications up to 1000V. Engineered for reliability and performance, this contactor from ABB - Electrification ensures seamless operation across a wide control voltage range of 48-130V, supporting both 50/60 Hz AC and DC systems. Ideal for demanding industrial environments, the AF205-30-11-12 delivers consistent performance with minimal maintenance, making it a cost-effective choice for modern electrical systems. Key features include: - High-voltage capability up to 1000V for versatile applications - Wide control voltage range (48-130V) for compatibility with diverse systems - Suitable for motor starting, isolation, bypass, and distribution tasks - Designed for durability and long operational life in industrial settings - Manufactured by ABB, a trusted name in electrification solutions The AF205-30-11-12 contactor is part of ABB's premium product line, ensuring compliance with industry standards and providing peace of mind for engineers and facility managers. Whether used in heavy machinery, HVAC systems, or power distribution networks, this contactor delivers the reliability and efficiency required for critical operations. Trust ABB's expertise to power your industrial applications with confidence.
  • 3-phase contactor for motor starting, isolation, bypass, and distribution
  • Rated for applications up to 1000V
  • Wide control voltage range: 48-130V (50/60 Hz and DC)
  • Manufactured by ABB - Electrification for reliability
  • UNSPSC Code: 39121529

Specifications

Rated Control Circuit Voltage
50 Hz /60 Hz DC Operation 48 ... 130 V
Special Features
A 3-phase Contactor suitable for various applications such as Motor starting, Isolation, By-pass and Distribution application up to max 1000 V. Operated with wide control voltage range 48-130 V, 50/60 Hz and DC
Terminal Type
Main Circuit: Bars
Package Dimensions (L x W x H)
8.661 IN x 7.874 IN x 11.024 IN
Package Dimensions (L x W x H)
21.9989 cm x 20 cm x 28.001 cm
Package Weight (Imperial)
7.260 L
Package Weight (Metric)
3.293 kg

Similar Products

AF205-30-11-11

Rated Control Circuit Voltage: 50 Hz /60 Hz 24 ... 60 V / DC Operation 20 ... 60 V

Voltage Rating: 1000 V

Frequency: 50/60 Hz

AF205-30-11-13

Rated Control Circuit Voltage: 50 Hz /60 Hz DC Operation 100 ... 250 V

Voltage Rating: 1000 V

Frequency: 50/60 Hz

AF205-30-11-14

Rated Control Circuit Voltage: 50 Hz /60 Hz DC Operation 250 ... 500 V

Voltage Rating: 1000 V

Frequency: 50/60 Hz

AF205-30-11-32

Voltage Rating: 48-130V DC

Current Rating: 300A

Poles: 3P

AF205-30-11-42

AF205-30-11-31

Voltage Rating: 24-60V AC/DC

Current Rating: 300A

Poles: 3P

You May Also Be Interested In

A 3-phase Contactor suitable for various applications such as Motor starting, Isolation, By-pass and Distribution application up to max 1000 V. Operated with wide control voltage range 48-130 V, 50/60 Hz and DC
