ABB - Electrification AF116-30-00-12 - A 3-phase Contactor suitable for various applications such as Motor starting, Isolation, By-pass and Distribution application up to max 690 V. Operated with wide control voltage range 48-130 V, 50/60 Hz and DC
ABB - Electrification

AF116-30-00-12

Documents & Media
Manufacturer Product Website

Contact for Pricing

Overview

The ABB Electrification AF116-30-00-12 is a robust 3-phase contactor engineered for demanding industrial environments. Designed for versatility, this contactor excels in a wide array of applications including critical motor starting, reliable isolation, efficient by-pass operations, and general power distribution up to a maximum voltage rating of 690 V. Its broad control voltage range, spanning from 48 to 130 V AC/DC at 50/60 Hz, ensures seamless integration into diverse electrical systems and facilitates flexible power management strategies. Engineered with ABB's renowned quality and reliability, the AF116 series contactors are built to withstand rigorous operational cycles. The 3-pole configuration is standard for 3-phase power control, making this unit suitable for a vast majority of industrial motor and power circuits. The wide control voltage flexibility is a key advantage, allowing for simplified inventory management and adaptability across different regions or system designs. Whether you are implementing new motor control centers, upgrading existing distribution panels, or requiring a dependable isolation switch for maintenance procedures, the AF116-30-00-12 offers a high-performance solution. Its robust construction and adherence to stringent manufacturing standards by ABB Electrification guarantee long-term operational stability and safety. This contactor is an essential component for maintaining efficient and secure electrical operations in manufacturing plants, processing facilities, and other industrial settings. The SKU AF116-30-00-12 signifies a specific configuration within the AF116 series, optimized for performance and compatibility. The UNSPSC code 39121529 further categorizes this product within the electrical switching and control equipment market. Manufactured in the USA, this contactor benefits from high-quality production standards and supply chain reliability.
  • 3-Phase Contactor for versatile industrial applications
  • Maximum Voltage Rating: 690 V
  • Wide Control Voltage Range: 48-130 V AC/DC, 50/60 Hz
  • Suitable for Motor Starting, Isolation, By-pass, and Distribution
  • ABB Electrification quality and reliability

Specifications

Rated Control Circuit Voltage
50 Hz /60 Hz DC Operation 48 ... 130 V
Special Features
A 3-phase Contactor suitable for various applications such as Motor starting, Isolation, By-pass and Distribution application up to max 690 V. Operated with wide control voltage range 48-130 V, 50/60 Hz and DC
Terminal Type
Double Clamp
Package Dimensions (L x W x H)
4.528 IN x 7.638 IN x 6.654 IN
Package Dimensions (L x W x H)
11.5011 cm x 19.4005 cm x 16.9012 cm
Package Weight (Imperial)
3.832 L
Package Weight (Metric)
1.738 kg
