Mersen plug fuses are intended for industrial and residential applications. Non time-delay fuses are available for receptacle and lighting circuits and time-delay fuses for motor loads. For Canadian requirements, a type P fuse is used for non-motor loads and Type D, for electrical heating and cyclical load circuits. Both fuses have low melting-point temperature elements. Type S plug fuses are time-delay and tamper resistant. 125 Volts 15 Amps GP series. 125 Volts 20 Amps GSL series.

Mersen R-Rated fuses are current-limiting, high interrupting rating fuses intended for the short circuit protection of medium voltage motors and motor controllers. R-Rated fuses are back-up fuses that have a minimum interrupting rating, and must be coordinated with overload relays in combination motor starters. The motor starter manufacturer generally specifies the R-Rated fuse size. These fuses come with a 3 (size D) or 4 (size E) inch diameter barrels with ferrules and are mounted in spring reinforced clips. 7200 Volts 2 R A720R Series.

250V Time Delay, Ceramic 1/4" x 1 1/4" 250 Volts 0.15 Amps GSA series.

The Shawmut Trigger Indicator is a field-mountable blown-fuse indicator which is wired parallel with the fuse to be monitored. The striker pin exerts a static force of one pound and be used to actuate a switch. It is available in 130 volt (TI-130), 600 vo 1500 Volts 70A or higher amps.

Current-limiting Amp-Trap A2K-R fuses provide excellent protection where high available short-circuit currents exist. These fast-acting fuses are particularly good for branch/feeder circuits and back-up protection. 250 Volts 1 amps.

700V external indicator

A13X Amp-trap Form 101 Semiconductor Protection fuses were designed for the specific protection of diodes and other semiconductor devices rated 130VAC. The A13X product line's compact design is perfect for those applications that have limitations on available space. 130 Volts 2000 Amps type 128 connection.

A13X Amp-trap Form 101 Semiconductor Protection fuses were designed for the specific protection of diodes and other semiconductor devices rated 130VAC. The A13X product line's compact design is perfect for those applications that have limitations on available space. 130 Volts 50 Amps type 4 connection.

A25Z Amp-trap Semiconductor Protection fuses are intended for the protection of Power Semiconductors such as Diodes, Phase Control SCR's and other power Semiconductor devices 250 Volts 8 Amps A25Z series.

A13X Amp-trap Form 101 Semiconductor Protection fuses were designed for the specific protection of diodes and other semiconductor devices rated 130VAC. The A13X product line's compact design is perfect for those applications that have limitations on available space. 130 Volts 250 Amps type 4 connection.

A13X Amp-trap Form 101 Semiconductor Protection fuses were designed for the specific protection of diodes and other semiconductor devices rated 130VAC. The A13X product line's compact design is perfect for those applications that have limitations on available space. 130 Volts 4000 Amps type 128 connection.

A13X Amp-trap Form 101 Semiconductor Protection fuses were designed for the specific protection of diodes and other semiconductor devices rated 130VAC. The A13X product line's compact design is perfect for those applications that have limitations on available space. 130 Volts 70 Amps type 4 connection.
