Contact for Pricing
Overview
- Unique counterflow aluminum core for high-efficiency and high-performance heat transfer, except for the XR20 and XR29-08 which use a modified heat pipe core
- Streamlined aesthetics with no visible mounting rails; slim design allows for mounting to narrow or shallow enclosures
- Models for 115 and 230 VAC power input
- Operating temperature range from -20 F/-29 C to 140 F/60 C
- Low-carbon mild-steel sheet-metal cover for rugged factory environments
- Filterless design for low maintenance and easy cleaning
- Reliable top-quality bearing fans and impellers make these units run quietly and with increased reliability
- Easy-mount flanges for simple installation
- Every unit functionally tested before shipping
- Mounting hardware, gaskets and user manual furnished with the unit
Specifications
Application | Controls and Drives; Power Distribution |
Capacity Watts Per degr.C | 7 W |
Capacity Watts Per degr.F | 4 W |
Color | Light Gray |
Color Code | RAL 7035 |
Depth | 3 IN |
Depth | 76 mm |
Finish | Powder Coated |
Frequency | 50/60Hz |
Height | 20 in |
Height | 508 mm |
Material | Mild Steel |
Max Current | 0.6 A |
Max Watts Per °F | 4 W |
Max Watts Per degr.C | 7 W |
Max Watts Per degr.F | 4 W |
Mechanical Advantage | Mild steel sheet metal standard |
Mounting Type | Surface-mounted |
NEMA Rating | 12 Indoor, dust-resistant |
Nominal Voltage | 115 V |
Operating Temperature | -20-140 °F |
Operating Temperature | -29-60 °C |
Product Family | ClimaGuard |
Protection Rating | NEMA Type 12 |
Series | ClimaGuard |
Thickness | 18 ga |
Thickness | 1.21 mm |
Type | Heat Exchangers |
Voltage AC | 100-120 V |
Voltage Rating | 115V |
Weight | 15 lb |
Weight | 5.4 kg |
Width | 191 mm |
Width | 7.5 in |
Package Dimensions (L x W x H) | 21.75 IN x 8.75 IN x 7.3 IN |
Package Dimensions (L x W x H) | 55.245 cm x 22.225 cm x 18.542 cm |
Package Weight (Imperial) | 15.000 L |
Package Weight (Metric) | 6.804 kg |
How to Install the XR200416012 Heat Exchanger
This guide provides step-by-step instructions for installing and configuring the XR200416012 heat exchanger for optimal performance.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the heat exchanger
Secure the XR200416012 heat exchanger to the designated mounting surface using the provided mounting screws. Ensure it is level and firmly attached to prevent vibrations.
- Connect the power supply
Using wire strippers, prepare the power supply wires and connect them to the terminal block of the heat exchanger. Ensure that the connections are tight and secure to prevent electrical issues.
- Verify electrical connections
Use a multimeter to check the voltage at the terminal block to ensure it matches the specifications of the heat exchanger. This step is crucial for safe operation.
- Configure the settings
Refer to the user manual to set the operational parameters of the heat exchanger. Adjust settings such as temperature and fan speed according to your requirements.
- Calibrate the unit
Run the heat exchanger for a short period and monitor its performance. Make any necessary adjustments to the settings to ensure optimal operation.
