Overview
- Specifically designed for type 4x food & beverage industry, indirect contact zone applications.
- Constructed from durable, corrosion-resistant 304 stainless steel.
- Maintains NEMA Type 4X rating when properly installed on compatible enclosures.
- Fixed height design provides stable and consistent enclosure elevation.
- Ideal for sanitary environments in food & beverage, pharmaceutical, and chemical industries.
Specifications
Application | Controls and Drives; Hygienic Environments; Corrosive Environments |
Application | Controls and Drives;Corrosive Environments;Hygienic Environments |
Color | Unpainted |
Finish | Brushed #4 |
Length | 16 IN |
Length | 12 in |
Length | 12-12 in |
Material | Stainless Steel 304 |
Material | Stainless Steel;Stainless Steel 304 |
Modification Services | Yes |
Product Family | WaterShed |
Size | 12 in |
Type | External Mounting for Industrial Enclosures |
Weight | 28.8 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 13.8 IN x 7.9 IN x 6.9 IN |
Package Dimensions (L x W x H) | 35.052 cm x 20.066 cm x 17.526 cm |
Package Weight (Imperial) | 28.800 L |
Package Weight (Metric) | 13.064 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the Sanitary Leg Kit
This guide provides step-by-step instructions for installing the Sanitary Leg Kit to stabilize your enclosure.
Estimated time: 30m
Tools needed:
Screwdriver, Wrench
Supplies needed:
Mounting screws, Hole seals
- Remove hole seals
Remove the hole seals from the bottom of the enclosure to prepare for leg installation.
- Mount the legs
Secure the legs to the enclosure using the provided mounting screws. Ensure that the legs are firmly attached and the enclosure is stable.
- Verify stability
Check that the enclosure is stable and secure before opening any doors. Follow the guidelines in the 'Large Enclosure Handling Manual' for safety.
