Overview
- Heavy-wall 3.5-in. structural tube welded to a 12 x 12 x 3/8-in.-thick baseplate
- Provides a "rough-in" point and pull box for power and network field wiring
- Includes internal CAT5 coupler and finger-safe power terminals
- Two conduit knock-outs can be opened to either 1/2 in. or 3/4 in.
- Fully gasketed 16 gauge cover panel on junction box can be used for additional conduit attachment
- Tough, molded ABS junction box is contoured to fit the post and is fluted into the post to protect cables
Specifications
Application | Controls and Drives |
Color | Light Gray |
Color | Lt Gray |
Color Code | RAL 7035 |
Depth | 102 mm |
Depth | 4 |
Depth | 102 |
Finish | Powder Coated |
Height | 5 |
Height | 127 |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Mounting Type | Post Mount |
NEMA Rating | 12 Indoor, dust-resistant |
Product Family | Syspend |
Protection Rating | NEMA Type 12 |
Series | Syspend VHD-Motion Arm |
Size | 5.00x4.00x4.00 in |
Size | 5.00x4.00x4.00 |
Type | Vertical Motion Arms |
Weight | 2.95 kg |
Weight | 4.4 lb |
Width | 102 mm |
Width | 4 |
Width | 102 |
Package Dimensions (L x W x H) | 6.6 IN x 4.5 IN x 5.2 IN |
Package Dimensions (L x W x H) | 16.764 cm x 11.43 cm x 13.208 cm |
Package Weight (Imperial) | 4.400 L |
Package Weight (Metric) | 1.996 kg |
How to Install the VHDPOST Controller
This guide provides step-by-step instructions for installing and configuring the VHDPOST Controller on a DIN rail.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the VHDPOST Controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect power supply
Use terminal connectors to connect the power supply wires to the designated input terminals on the VHDPOST Controller. Ensure the connections are tight and secure.
- Verify connections
Use a multimeter to check the voltage at the input terminals to ensure the power supply is functioning correctly. Confirm that the voltage matches the specifications outlined in the VHDPOST documentation.
- Configure the controller
Follow the programming instructions in the VHDPOST documentation to set up the controller parameters according to your application requirements.
- Calibrate the system
Perform any necessary calibration procedures as specified in the VHDPOST documentation to ensure accurate operation.
