Overview
- For use with Ultrx Series Products
- Copper construction with green/yellow color coding for quick identification
- Designed for nVent ULTRX Swing-Out Panels or Swing-Out Frames
- Includes all installation hardware and comprehensive instructions
- Swing-out design enables easy access for maintenance and inspections
- Corrosion-resistant and durable for long-term reliability in industrial environments
- Trusted brand with over a century of expertise in electrical solutions
Specifications
Application | Corrosive Environments; Controls and Drives |
Application | Controls and Drives;Corrosive Environments |
Color | Green/Yellow |
Color | Green |
Finish | Insulated |
Material | Copper |
Modification Services | Yes |
Mounting Type | Swing-out panel mount |
Product Family | Ultrx |
Series | ULTRX |
Thickness | 51.40mm (2.024") |
Thickness | 12 ga |
Type | Networking Accessories |
Weight | 0.16 lb |
Package Dimensions (L x W x H) | 8.25 IN x 6 IN x 0.25 IN |
Package Dimensions (L x W x H) | 20.955 cm x 15.24 cm x 0.635 cm |
Package Weight (Imperial) | 0.160 L |
Package Weight (Metric) | 0.073 kg |
A100125GR
PVC Wiring Duct (Carton Qty12), Bulletin A80 (Accessories - Misc. - Open Slot Wiring Duct & Accessories), Size/Dims: 1.00x1.25x72.00, Material: PlasticA200500GR
PVC Wiring Duct (Carton Qty12), Bulletin A80 (Accessories - Misc. - Open Slot Wiring Duct & Accessories), Size/Dims: 2.00x5.00x72.00, Material: Plastic
How to Install the Ground Kit for ULTRX®
This guide provides step-by-step instructions for safely installing the Ground Kit for ULTRX® systems.
Estimated time: 30m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Prepare the installation area
Ensure the installation area is clean and free of debris. Verify that all necessary tools and supplies are available before proceeding.
- Mount the ground kit
Secure the ground kit to the designated location using the provided mounting screws. Ensure it is firmly attached and level.
- Connect the grounding wires
Strip the ends of the grounding wires and connect them to the terminal connectors on the ground kit. Use a multimeter to verify proper connections.
- Test the installation
After all connections are made, use a multimeter to test the continuity of the grounding system. Ensure that all connections are secure and functioning correctly.
