nVent SBK20088 - Seismic Bracket Kit, SBK, 1961x710x735mm, Zinc Plated, Mild Steel
nVent

SBK20088

UPC: 783510527747

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent SBK20088 Seismic Bracket Kit (SKU: SBK20088) provides essential structural reinforcement for nVent floor-standing enclosures measuring 2000mm (H) x 800mm (W) x 800mm (D). Engineered to enhance stability, this kit is crucial for installations in seismic zones or areas prone to severe vibrations. The kit features side bars constructed from 4mm galvanized steel and brackets made from 3mm galvanized steel, ensuring durability and corrosion resistance. Its design incorporates a rear cross-bar and side bracing to significantly increase the enclosure's frame rigidity. This reinforcement enables the enclosure to withstand accelerations up to 1g in all directions, safeguarding sensitive electronic, electrical, and control systems. Installation requires depth mounting via CLPK Click-in profiles and width mounting with CB carrier bars at the top and bottom of the enclosure, adhering to seismic testing standards. The SBK20088 is an indispensable accessory for applications in manufacturing facilities, data centers, utility substations, and any environment where equipment stability is paramount. Trust nVent, a leader in electrical enclosure solutions, for reliable protection of your valuable assets.
  • Designed for nVent enclosures: 2000mm (H) x 800mm (W) x 800mm (D)
  • Withstands accelerations up to 1g in all directions for seismic compliance
  • Durable construction: 4mm galvanized steel side bars, 3mm galvanized steel brackets
  • Enhances enclosure rigidity with cross-bar and side bracing
  • Requires CLPK Click-in profiles and CB carrier bars for installation

Specifications

Application
Controls and Drives; Factory Automation and Process Control
Color
Black
Depth
28.93702
Depth
31.49 in
Depth
800 mm
Depth
28.94
Depth
735
Enclosure Material
Mild Steel
Finish
Galvanized
Height
2,000 mm
Height
77.20477
Height
78.74 in
Height
77.2
Height
1,961
Material
Mild Steel
Package Quantity
1
Product Family
Free-Standing
Type
Mounting
Type
IEC Enclosure Accessories
Width
27.95
Width
710
Width
800 mm
Width
31.49 in
Width
27.95277
Works With
IEC
Package Weight (Imperial)
28.700 L
Package Weight (Metric)
13.018 kg
