Contact for Pricing
Overview
- Slim Fit Design with three mounting options; fully recessed, partial recessed and surface mount
- Aesthetic design plastic cover to optimize air flow
- R134a refrigerant
- Voltage: 230 V (50/60 Hz), 115 V (50/60 Hz) and 400/460 V 3-phase (50/60 Hz)
- Operating temperature range from 50 F / 10 C to 131 F / 55 C
- Easy filter replacement for extremely dusty environments
- Dust resistant coils for filterless operation
- Active condensate management to prevent dripping water
- Energy efficient rotary compressor
- Terminal block power input
Specifications
Application | Controls and Drives;Power Distribution |
Application | Power Distribution; Controls and Drives |
Color | Light Gray |
Color | Gray |
Color Code | RAL 7035 |
Depth | 259 mm |
Depth | 10.2 in |
Finish | Powder Coated |
Height | 37.4 in |
Height | 950 mm |
Material | Mild Steel |
Max Current | 8 A |
NEMA Rating | 12 Indoor, dust-resistant |
Nominal Capacity Btu/h | 3,400 Btu/h |
Nominal Capacity Watts | 1,000 W |
Nominal Voltage | 460 V |
Number Of Phases | 1 |
Operating Temperature | 10-55 °C |
Operating Temperature | 50-131 |
Operating Temperature | 10-55 |
Product Family | SpectraCool Slim Fit |
Protection Rating | NEMA Type 12 |
Remote Access Control | No |
Thickness | 1.21 mm |
Thickness | 18 ga |
Thickness | 51.40mm (2.024") |
Type | Air Conditioners |
Voltage AC | 400-460 V |
Voltage Rating | 400 - 460 VAC |
Weight | 45 kg |
Weight | 115 lb |
Width | 399 mm |
Width | 15.7 in |
Package Dimensions (L x W x H) | 20 IN x 14 IN x 40 IN |
Package Dimensions (L x W x H) | 50.8 cm x 35.56 cm x 101.6 cm |
Package Weight (Imperial) | 115.000 L |
Package Weight (Metric) | 52.164 kg |
How to Install the SPECTRACOOL Slim Fit Air Conditioner
This guide provides step-by-step instructions for installing and setting up the SPECTRACOOL Slim Fit Air Conditioner, ensuring proper functionality and safety.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors, Mounting gasket
- Inspect the air conditioner
Verify the air conditioner's functionality before mounting. Ensure it has been upright for at least five minutes if it was previously horizontal.
- Mount the air conditioner
Using the provided gasket, attach it to the air conditioner. Secure the unit to the enclosure with the supplied grub screws, washers, and nuts, ensuring not to damage the gasket.
- Connect the power supply
Loosen the screw on the evaporator access panel and remove it. Route the power supply wire through the strain relief and connect it to the terminal block as labeled. Reinstall the access panel and tighten the strain relief screw.
- Verify electrical connections
Ensure that the power supply wiring is properly grounded and that no other equipment is connected to the same circuit to prevent overload.
- Initial operation check
After applying power, check that the evaporator blower starts running. Set the cooling controller to a temperature below the ambient temperature to operate the compressor.
- Calibrate the controller
Adjust the controller to the desired cabinet temperature, ensuring the cooling set-point is configured correctly for your needs.
