Overview
- Available sized from 6x6 (152x152mm) to 30x24 (762x610mm)
- All VJ enclosures were designed to meet the Joint Industrial Council (JIC) standards in the United States
- Enclosures are maintenance free and corrosion resistant
- Made from hot compression molded halogen free, self extinguishing fiberglass reinforced polyester (FRP)
- Polyurethane foam-in-place gasket
- Molded mounting flanges and cover corner ribs increase enclosure strength
- Enclosures can be modified to customer specifications
- Enclosures can be modified to customer specifications
Specifications
Application | Controls and Drives;Corrosive Environments |
Color | Light Gray |
Color | Gray |
Color | Grey |
Color Code | RAL 7035 |
Depth | 125 mm |
Depth | 4.92 in |
Finish | Smooth Matte |
Height | 9.32 |
Height | 237 mm |
Material | Fiberglass |
Material Quality | Fiberglass |
Product Family | VJ |
Protection Rating | NEMA Type 3 |
Style | Non-metallic hinges and stainless steel padlockable latch |
Type | Fiberglass and Thermoplastic Wall Mounted Industrial Enclosures |
Weight | 3.8 lb |
Width | 186 mm |
Width | 7.32 in |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the 95HCD Hinged Inspection Window
This guide provides step-by-step instructions for installing the 95HCD Hinged Inspection Window on your enclosure.
Estimated time: 45m
Tools needed:
Screwdriver, Drill, Wire strippers
Supplies needed:
Mounting screws, Neoprene gasket, Air vents
- Prepare the enclosure
Ensure the enclosure is clean and free of debris. Identify the mounting location for the inspection window.
- Install the hinged inspection window
Align the window with the pre-drilled holes on the enclosure. Secure the window using the provided mounting screws, ensuring it is tightly fitted.
- Seal the window
Apply the neoprene gasket around the window frame to prevent moisture ingress. Ensure the gasket is evenly placed and free of gaps.
- Install air vents
Drill holes for the air vents in the upper and lower parts of the enclosure. Install the air vents using the provided screws to ensure proper air circulation.
- Verify installation
Check that the window opens and closes smoothly. Inspect the gasket and air vents for proper installation and seal.
