Contact for Pricing
Overview
- Designed for nVent Quick Tray Pro cable tray systems
- Provides effective separation of power, data, and communication cables
- Constructed from durable black steel for industrial environments
- 5-foot (1.5-m) length for versatile application
- Requires QTPSSW3/QTPSSW3BLK Splice Washer and QTPBNWK/QTPBNWKBLK Splice Kit for secure installation
Specifications
Application | Networking, Storage and Data Center |
Color | Jet Black |
Color Code | RAL 9005 |
Modification Services | No |
Product Family | QuickTray Pro |
Thickness | 22 |
Tray Height | 51 mm |
Type | Cable Pathway |
Weight | 3 lb |
Package Dimensions (L x W x H) | 62.25 IN x 4.25 IN x 4.25 IN |
Package Dimensions (L x W x H) | 158.115 cm x 10.795 cm x 10.795 cm |
Package Weight (Imperial) | 3.000 L |
Package Weight (Metric) | 1.361 kg |
How to Install and Configure QTPDS2BLK Cable Tray
This guide provides instructions for cutting, bending, and connecting sections of the QUICK TRAY PRO™ Cable Tray system, including the QTPDS2BLK model, to create custom cable management installations.
Estimated time: 1h 30m
Tools needed:
QTPBC Side Action Bolt Cutter, Wrench
Supplies needed:
QUICK TRAY PRO™ Cable Tray (e.g., QTPDS2BLK), QTPBNWK Splice Kit, QTPSSW3 Splice Washer, QTPUS10 Universal Splice Bar, QTP90TKIT T-Connection or 90o Splice Bar, Cable tray supports
- Cut Cable Tray Sections
Always use the Hoffman side action bolt cutter to cut the QUICK TRAY PRO™ Cable Tray. Decide which wires must be cut based on the desired configuration, reviewing the cutting pattern for specific bends. Start by cutting the top side wire, positioning the cutting jaws on the cradle wire and cutting at an angle away from the new end. Repeat this process for all remaining side wires. Turn the tray over and cut the bottom wires from the underside, always resting the cutting jaws on the cradle wire and cutting at an angle away from the new end. Make one clean cut to eliminate grinding or touch-up and minimize sharp edges.
- Form a 90-Degree Bend
At the desired bend location, cut the wires shown in red for your specific tray width. Cut all side wires at the bend location. Turn the tray on the uncut side and smoothly bend the tray up until the inside edges closest to the uncut side meet. Secure the bend by fastening at the indicated locations with QTPBNWK/QTPBNWKBLK Splice Kits and QTPSSW3/QTPSSW3BLK Splice Washers, ensuring they are appropriate for the tray width.
- Connect Cable Tray Sections
To connect straight sections or form complex configurations like elbows or tees, align the wires of the two tray sections at the desired angle. Fasten the tray using QTPBNWK/QTPBNWKBLK Splice Kits and QTPSSW3/QTPSSW3BLK Splice Washers. For adjustable angles, use one splice kit and one splice washer, centered, ensuring each splice washer covers two tray bottom wires. For additional support, use QTPUS10/QTPUS10BLK Universal Splice Bars with fasteners, cutting them to fit if necessary.
- Support the Cable Tray Installation
Install straight section supports at typical 6-foot (1.5m) centers. Ensure supports are placed within 24 inches (610mm) of any splice on straight sections. The span between supports must not exceed the length of the tray. Provide additional supports around bends and wherever the cable tray level changes to maintain stability and ensure proper load distribution.
