Contact for Pricing
Overview
- Durable black steel construction for enhanced corrosion resistance and professional appearance.
- Designed for connecting nVent Quick Tray Pro sections, splice bars, turns, bends, and tees.
- Includes a complete three-piece staked bolt, washer, and nut fastening solution.
- Compact dimensions: 2.00 x 4.00 x 2.00 inches.
- Packaged in quantities of 50 units for project efficiency.
Specifications
Application | Networking, Storage and Data Center |
Color | Jet Black |
Color Code | RAL 9005 |
Modification Services | No |
Product Family | QuickTray Pro |
Thickness | 0.19 in |
Type | Cable Pathway |
Weight | 3.3 lb |
Package Dimensions (L x W x H) | 5.6 IN x 3.6 IN x 3.2 IN |
Package Dimensions (L x W x H) | 14.224 cm x 9.144 cm x 8.128 cm |
Package Weight (Imperial) | 3.300 L |
Package Weight (Metric) | 1.497 kg |
How to Connect QUICK TRAY PRO™ Cable Tray Sections Using the QTPBNWKBLK Splice Kit
This guide details the proper use of the QTPBNWKBLK Splice Kit to securely connect QUICK TRAY PRO™ cable tray sections, bends, and tees. The kit provides essential hardware for robust cable tray assembly.
Estimated time: 5m
Tools needed:
Wrench, Pliers
Supplies needed:
QTPBNWKBLK Splice Kit, QTPSSW3/QTPSSW3BLK Splice Washers, QUICK TRAY PRO™ Cable Tray sections, QUICK TRAY PRO™ Splice Bars (if applicable)
- Prepare and Align Tray Sections
Align the QUICK TRAY PRO™ cable tray sections, bends, or splice bars at the desired connection point. Ensure the components are properly positioned and ready for fastening according to your installation design.
- Position Splice Washer and Insert Bolt
Place a QTPSSW3 or QTPSSW3BLK Splice Washer over the connection point, ensuring it spans across the wires of the tray sections or splice bar. Insert the staked bolt from the QTPBNWKBLK Splice Kit through the splice washer and the aligned tray wires.
- Secure the Connection
Thread the nut from the QTPBNWKBLK Splice Kit onto the staked bolt. Use a wrench or pliers to tighten the nut securely, ensuring a firm and stable connection between the cable tray components. Repeat for all required splice points.
