Overview
- For routing and bundling cables
- Mounts vertically to grid straps or to mounting channels
- Three-piece kit adjusts to fit rack height and eliminates need for center grid strap
- Includes 10 black 8-inch (203mm) long Velcro™ cable wraps
- Narrow profile does not interfere with 19-inch equipment in 600mm-wide enclosures
Specifications
Application | Networking, Storage and Data Center |
Color | Jet Black |
Color | Black |
Color Code | RAL 9005 |
Finish | Powder Coated |
Material | Steel |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Mounting Type | Vertical mount to grid straps or mounting channels |
Mounting Type | Vertical Mounting (Grid Straps or Mounting Channels) |
Product Family | ProLine |
Series | PVCM2 |
Thickness | 1.52 mm |
Thickness | 16 ga |
Thickness | 51.40mm (2.024") |
Type | Rack and Cabinet Cable Management |
Weight | 7.9 lb |
Package Dimensions (L x W x H) | 33 IN x 6.2 IN x 3.4 IN |
Package Dimensions (L x W x H) | 83.82 cm x 15.748 cm x 8.636 cm |
Package Weight (Imperial) | 7.900 L |
Package Weight (Metric) | 3.583 kg |
How to Install the Vertical Cable Manager for Cabinet Center
This guide provides step-by-step instructions for installing the Vertical Cable Manager in a cabinet, ensuring proper cable management and organization.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Velcro straps
- Mount the cable manager
Secure the cable manager to the cabinet using the provided mounting screws. Ensure it is level and firmly attached.
- Organize cables
Use Velcro straps to secure cables within the cable manager. Ensure that cables are neatly arranged to prevent tangling.
- Verify installation
Check that the cable manager is securely mounted and that all cables are properly organized and secured with Velcro straps.
