Contact for Pricing
Overview
- Solid Tops are finished with paint over plated surfaces
- Solid Tops are gasketed and include ground studs
- Bolts are included to hold the top in place (lifting eyes can be used instead of bolts)
- Ground studs included for proper electrical grounding
- Bolts included; optional lifting eyes for easy installation
Specifications
Application | Controls and Drives; Power Distribution |
Color | Light Gray |
Color | Painted |
Color Code | RAL 7035 |
Fits Frame | 800 x 800 mm |
Frame Type | Single-Bay |
IP Rating | IP55 |
Ip Rating | IP66/IP67 |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Mounting Type | Bolts with optional lifting eyes |
Product Family | ProLine |
Series | PT |
Size | fits 800x800mm |
Size | 800x800mm |
Thickness | 1.52 mm |
Thickness | 16 ga |
Type | Steel |
Weight | 22.4 lb |
Package Dimensions (L x W x H) | 35 IN x 35 IN x 2.25 IN |
Package Dimensions (L x W x H) | 88.9 cm x 88.9 cm x 5.715 cm |
Package Weight (Imperial) | 22.400 L |
Package Weight (Metric) | 10.161 kg |
