nVent PT128 - Solid Tops, fits 1200x800mm, Painted
nVent

PT128

UPC: 783510967307

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The **nVent PT128 Solid Top** is a precision-engineered closure panel designed to securely seal the top opening of industrial enclosures, ensuring optimal protection for sensitive electronic components and control systems. Manufactured by nVent, a global leader in thermal management and electrical protection solutions, the PT128 Solid Top is engineered to meet stringent electromagnetic compatibility (EMC) requirements while providing durability and ease of installation. This solid top is specifically designed to fit enclosures with a 1200x800mm footprint, making it an ideal choice for medium to large-scale industrial applications where robust protection and compliance are critical. The PT128 Solid Top features a **painted finish over plated surfaces**, delivering enhanced corrosion resistance and a professional appearance suitable for cleanroom, manufacturing, and outdoor environments. The top is **gasketed** to provide an IP-rated seal, preventing dust, moisture, and electromagnetic interference from compromising enclosed equipment. Additionally, the inclusion of **ground studs** ensures proper grounding, reducing the risk of static discharge and electrical hazards—a critical consideration in high-voltage or sensitive electronic applications. Installation is straightforward, with **bolts included** to secure the top in place, though optional lifting eyes can be used for ergonomic handling during maintenance or upgrades. This versatility makes the PT128 an excellent choice for facilities requiring frequent access to enclosed systems without sacrificing protection. The solid top’s design aligns with industry standards for EMC shielding, making it a trusted solution for industries such as **automation, telecommunications, data centers, and industrial automation**, where equipment reliability and regulatory compliance are paramount. nVent’s reputation for innovation and quality ensures that the PT128 Solid Top delivers consistent performance across diverse operating conditions. Whether used in **NEMA-rated enclosures, control panels, or industrial machinery housings**, this product provides the structural integrity and environmental protection needed to extend the lifespan of critical systems. Professionals in electrical engineering, facility management, and industrial design rely on nVent’s solutions for their proven reliability, ease of integration, and adherence to global safety standards. For engineers and procurement specialists seeking a **cost-effective, high-performance closure solution**, the nVent PT128 Solid Top offers a balance of durability, compliance, and ease of use. Its compatibility with standard enclosure frames and optional lifting features further enhance its practicality in dynamic industrial settings. Trusted by industry leaders worldwide, nVent’s PT128 Solid Top is a smart investment for any operation prioritizing equipment safety, regulatory compliance, and operational efficiency.
  • Solid Tops are finished with paint over plated surfaces
  • Solid Tops are gasketed and include ground studs
  • Bolts are included to hold the top in place (lifting eyes can be used instead of bolts)
  • Ground studs and bolts included for easy installation
  • Optional lifting eyes for ergonomic handling

Specifications

Application
Controls and Drives; Power Distribution
Color
Light Gray
Color Code
RAL 7035
Fits Frame
1200 x 800 mm
Frame Type
Double-Bay
IP Rating
IP55
Material
Mild Steel
Modification Services
Yes
Product Family
ProLine
Size
fits 1200x800mm
Size
1200x800mm
Thickness
16 ga
Thickness
1.52 mm
Type
Steel
Weight
30.76 lb
Package Dimensions (L x W x H)
51 IN x 38 IN x 1.5 IN
Package Dimensions (L x W x H)
129.54 cm x 96.52 cm x 3.81 cm
Package Weight (Imperial)
30.760 L
Package Weight (Metric)
13.953 kg
