nVent PSS225HF2 - Solid Sides, fits 2200x500mm, EMC
nVent

PSS225HF2

UPC: 783510169596

Documents & Media
Installation Instructions

Contact for Pricing

Overview

Enhance your enclosure's environmental and electromagnetic protection with the nVent PSS225HF2 Solid Sides. Designed to seamlessly integrate with enclosure frames, these solid sides provide a robust solution for sealing open areas, ensuring superior protection against dust, moisture, and electromagnetic interference (EMI/RFI). The PSS225HF2 is specifically engineered for 2200x500mm enclosure dimensions, offering a precise fit and contributing to the overall structural integrity of your cabinet. Crafted by nVent, a leader in electrical enclosure solutions, the PSS225HF2 exemplifies quality and reliability. These solid sides are not merely passive barriers; they actively contribute to the performance and longevity of your sensitive electronic equipment. The "EMC" designation signifies their capability to mitigate electromagnetic interference, a critical factor in environments with high levels of electrical noise, such as industrial automation, telecommunications, and data centers. By reducing EMI/RFI, these sides help maintain signal integrity and prevent malfunctions in your connected devices. The installation process is streamlined for efficiency. The solid sides attach to the enclosure frame using semi-flush screws, ensuring a clean and professional finish. To further simplify alignment and mounting, integrated hangers are included, allowing for easy positioning of screws and a quicker assembly time. This attention to detail in design translates to reduced labor costs and less downtime during enclosure setup or modification. Key features and benefits of the nVent PSS225HF2 Solid Sides include: * **Comprehensive Sealing:** Solid sides effectively close open sections of enclosure frames, preventing ingress of environmental contaminants. * **EMC Protection:** Designed to offer medium levels of EMI/RFI shielding, crucial for maintaining signal integrity in noisy electrical environments. * **Robust Construction:** Manufactured by nVent, ensuring durability and long-term performance in demanding industrial settings. * **Easy Installation:** Features semi-flush screw attachment and included hangers for simplified alignment and mounting. * **Grounding Capability:** Equipped with two grounding studs, facilitating proper electrical grounding of the enclosure system. * **Foam-in-Place Gasket:** Incorporates a high-quality foam-in-place gasket for superior sealing against dust and moisture. * **Precise Fit:** Specifically designed for 2200x500mm enclosure dimensions, ensuring a secure and gap-free integration. It is important to note that while these solid sides provide excellent sealing and EMC performance, they are not intended for use as structural barriers between joined enclosures. Their primary function is to seal individual enclosure frames. The inclusion of mounting hardware further simplifies the deployment of this essential enclosure accessory. Trust nVent for your critical enclosure needs, and ensure your equipment is protected with the PSS225HF2 Solid Sides.
  • Solid Sides are finished with paint over plated surfaces
  • Provides medium EMI/RFI shielding for sensitive electronics.
  • Designed for 2200x500mm enclosure dimensions.
  • Includes hangers for easy screw alignment and mounting.
  • Features two grounding studs and a foam-in-place gasket for superior sealing.

Specifications

Application
Controls and Drives;Power Distribution
Color
Light Gray
Color
Gray
Color
Grey
Color Code
RAL 7035
Dimensions
28W x 10D x 10H IN
Dimensions
84.21 x 17.83 in
Fits Frame
2200 x 500 mm
Fits Frame
1400 x 1200 mm
IP Rating
IP55
Material
Metal
Material
Mild Steel;Steel
Material
Mild Steel
Modification Services
Yes
Mounting Type
Semi-flush screws
Product Family
ProLine
Series
Solid Sides
Size
2200x500mm
Size
fits 2200x500mm
Thickness
1.52 mm
Thickness
16 ga
Thickness
51.40mm (2.024")
Type
EMC
Type
External Mounting for ProLine Industrial Enclosures
Weight
36 lb
Works With
NEMA
Package Dimensions (L x W x H)
86 IN x 24 IN x 3 IN
Package Dimensions (L x W x H)
218.44 cm x 60.96 cm x 7.62 cm
Package Weight (Imperial)
36.000 L
Package Weight (Metric)
16.330 kg
