Contact for Pricing
Overview
- Convenient component mounting inside APO enclosures
- Available in three materials, aluminum, steel and non-metallic
- Precisely sized at 15.35x15.35x0.06 inches for PolySafe enclosures.
- Facilitates organized and secure internal component mounting.
- Ideal for industrial automation, control systems, and telecommunications.
Specifications
Application | Corrosive Environments; Controls and Drives |
Color | Light Gray |
Color | Powder Coated |
Color Code | RAL 7035 |
Depth | 2 mm |
Depth | 0.06 in |
Finish | Powder Coated |
Height | 15.35 in |
Height | 390 mm |
Material | Mild Steel |
Mounting Type | Mounting Plate |
Series | PolySafe |
Size | 15.35x15.35x0.06 inches |
Size | 15.35x15.35x0.06 |
Thickness | 0.06 IN |
Thickness | 2 mm |
Type | Industrial Panels and Panel Accessories |
Width | 390 mm |
Width | 15.35 in |
Works With | NEMA / IEC |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the Polysafe Enclosure
This guide provides step-by-step instructions for installing and configuring the Polysafe enclosure for electrical and electronic controls.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the enclosure
Secure the enclosure to the desired surface using the provided mounting screws. Ensure it is level and firmly attached.
- Connect the wiring
Use wire strippers to prepare the wires and connect them to the terminal connectors inside the enclosure. Ensure all connections are tight and secure.
- Verify electrical connections
Use a multimeter to check the voltage and continuity of the connections. Ensure that all readings are within the specified range.
- Seal the enclosure
Close the enclosure doors and ensure that the gaskets are properly seated to maintain the enclosure's IP65 rating.
- Calibrate the system
Follow the manufacturer's guidelines to calibrate any installed equipment within the enclosure, ensuring optimal performance.
