Overview
- Furnished in pairs
- Tapped-Hole Rack Angles are constructed from 12 gauge conductive steel, while Square-Hole Rack Angles are 14 gauge conductive steel; U-shaped, channel construction
- Tapped-Hole Rack Angles have 10-32 threaded holes; Square-Hole Rack Angles are designed to accept metric or English cage nuts. Comply with ANSI/EIA RS-310-D rack mounting standards.
- Rack Angles fit directly into 600-mm wide frames; other widths require Frame Reducing Brackets or Adjustable Rack-Mounting Rails (sold separately).
- Manufactured by nVent, a trusted leader in electrical and data infrastructure solutions
Specifications
Application | Controls and Drives |
Color | Unpainted |
Finish | Plated |
Fits Frame | 1600 mm mm |
Hole Type | Square |
Material | Mild Steel |
Modification Services | Yes |
Product Family | ProLine |
Rack Units | 33 |
Size | fits 1600mm |
Thickness | 14 ga |
Thickness | 1.9 mm |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 14 lb |
Package Dimensions (L x W x H) | 86.5 IN x 5.5 IN x 5 IN |
Package Dimensions (L x W x H) | 219.71 cm x 13.97 cm x 12.7 cm |
Package Weight (Imperial) | 14.000 L |
Package Weight (Metric) | 6.350 kg |
