Overview
- Available in gray (RAL 7042) or black
- Mounting hardware included
- Operating temperature range: -35°C to 130°C
- Includes aluminum filter mesh and all mounting hardware
- UV-stabilized for outdoor durability and debris protection
Specifications
Application | Controls and Drives; Power Distribution |
Color | Black |
Depth | 26 mm |
Depth | 1.03 in |
Finish | Smooth Matte |
Height | 300 mm |
Height | 11.81 in |
Material | Plastic |
Material | Composite |
Mounting Type | Hardware Included |
Product Family | ProLine |
Series | PPV |
Size | 300x200mm |
Type | Fans and Filter Fans |
Type | Cooling Accessories |
Weight | 1.9 lb |
Width | 7.88 |
Width | 200 |
Width | 200 mm |
Package Dimensions (L x W x H) | 12.1 IN x 8.5 IN x 1.5 IN |
Package Dimensions (L x W x H) | 30.734 cm x 21.59 cm x 3.81 cm |
Package Weight (Imperial) | 1.900 L |
Package Weight (Metric) | 0.862 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the Air Inlet Grille and Filter
Step-by-step guide for installing the air inlet grille and filter into an enclosure.
Estimated time: 30m
Tools needed:
Drill, Screwdriver
Supplies needed:
#6–32 self-tapping screws, Barrier, Filter, Air inlet grille
- Cut the enclosure
Make a 7.25 x 10.81 inch cutout into the enclosure as specified.
- Position the barrier
Using the barrier as a template, position the barrier into the cutout with the top flange offset. Drill four (4) .110 inch diameter holes into the enclosure.
- Secure the barrier
Fasten the barrier into position using the four (4) #6–32 self-tapping screws.
- Insert the filter
Place the filter into the barrier.
- Attach the grille
Hook the grille on the top flange of the barrier and pivot it down into a secured position.
