Overview
- Bars are plated copper with M6 and M5 tapped holes; mounting bracket is insulated
- Fits all enclosures if mounted vertically; for depth-mounting, 200mm length fits 400mm deep frame, 400mm fits 600mm, and 600mm fits 800mm
- Mounting hardware and M5, M6 fasteners for grounding included
- Mounting hardware and M5, M6 fasteners for grounding included
- UL Component Recognized (File No. E61997)
Specifications
Application | Controls and Drives; Power Distribution |
Color | Unpainted |
Finish | Plated |
Hole/Screw Quantity, M5 | 10/10 |
Hole/Screw Quantity, M6 | 3/5 |
Length | 200 mm |
Length | 7.87 in |
Material | Copper |
Modification Services | Yes |
Mounting Type | Vertical/Horizontal |
Product Family | ProLine |
Series | Grounding Bar System |
Size | 200mm |
Thickness | 0.25 in |
Thickness | 6.4 mm |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 0.72 lb |
Package Dimensions (L x W x H) | 11.3 IN x 9.3 IN x 0.9 IN |
Package Dimensions (L x W x H) | 28.702 cm x 23.622 cm x 2.286 cm |
Package Weight (Imperial) | 0.720 L |
Package Weight (Metric) | 0.327 kg |
