Overview
- Includes a handle and all mounting hardware to affix to Heavy-Duty Swing-Out Rack Frame
- RAL 7035 polyester powder paint, textured light gray
- C-justified mounting for precise installation
- Durable steel construction with RAL 7035 light gray finish
- Includes handle and all necessary mounting hardware
Specifications
Application | Controls and Drives |
Color | Light Gray |
Color | Gray |
Color | Grey |
Color Code | RAL 7035 |
Enclosure Width | 800 mm |
Enclosure Width | 700 mm |
Finish | Powder Coating |
Finish | Powder Coated |
Material | Steel |
Material | Mild Steel;Steel |
Material | Mild Steel |
Modification Services | Yes |
Mounting | Center |
Mounting Type | C-justified |
Mounting Type | Mounting to Swing-Out Rack Frame |
Mounting Type | Swing-Out Rack Frame Mounting |
Product Family | ProLine |
Series | ProLine |
Series | nVent ProLine Heavy-Duty |
Series | ProLine G2 |
Series | ProLine Heavy-Duty Swing-Out Rack Frames |
Size | 2200x800 |
Size | 2200x800 mm |
Swing Frame Height | 2200 mm |
Swing Frame Height | 1600 mm |
Thickness | 51.40mm (2.024") |
Thickness | 1.9 mm |
Thickness | 14 ga |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 22 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 82 IN x 6 IN x 4 IN |
Package Dimensions (L x W x H) | 208.28 cm x 15.24 cm x 10.16 cm |
Package Weight (Imperial) | 22.000 L |
Package Weight (Metric) | 9.979 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
