Overview
- The ProLine Frame Floor-Mounting Bracket provides a structural method of bolting a ProLine frame to the floor
- The bracket fits all frame sizes, the kit includes four brackets and mounting hardware
- This bracket is not to be used with colocation frames, which include welded-in floor mounting brackets
- Kit includes four brackets and all necessary mounting hardware.
- Manufactured in the USA.
Specifications
Application | Networking, Storage and Data Center |
Color | Light Gray |
Color | Gray |
Color Code | RAL 7035 |
Finish | Powder Coated |
Material | Steel |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Mounting Type | Floor-Mounting |
Product Family | ProLine |
Series | ProLine |
Thickness | 2.66 mm |
Thickness | 12 ga |
Thickness | 51.40mm (2.024") |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 1.14 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 5.7 IN x 5.4 IN x 5.3 IN |
Package Dimensions (L x W x H) | 14.478 cm x 13.716 cm x 13.462 cm |
Package Weight (Imperial) | 1.140 L |
Package Weight (Metric) | 0.517 kg |
How to Install the PFBK Frame Floor-Mount Bracket
This guide provides step-by-step instructions for installing the PFBK Frame Floor-Mount Bracket securely to ensure stability and proper function.
Estimated time: 30m
Tools needed:
Screwdriver, Drill
Supplies needed:
Mounting screws, M5x10 screws, Washers
- Prepare the installation area
Clear the installation area of any debris and ensure the floor is level. Mark the locations for the mounting holes based on the bracket dimensions.
- Drill mounting holes
Using a drill, create holes at the marked locations. Ensure the holes are of appropriate size for the mounting screws.
- Secure the bracket
Align the PFBK Frame Floor-Mount Bracket with the drilled holes and secure it using M5x10 screws and washers. Tighten the screws firmly to ensure stability.
