Contact for Pricing
Overview
- Elastomer keyboard/mouse combination is integrated into the keyboard shelf
- Cables supplied are compatible with USB connections
- Rear surface is gasketed to maintain both UL and CSA integrity
- Gasketed rear surface maintains UL and CSA enclosure integrity
- Dimensions: 173 x 562 x 323 mm (H x W x D), fits 19-inch racks
Specifications
Application | Controls and Drives |
Color | Unpainted |
Color | Brushed |
Connection Type | USB |
Depth | 324 mm |
Depth | 12.75 |
Depth | 324 |
Finish | Brushed |
Height | 173 mm |
Height | 6.81 |
Height | 173 |
Material | SS304 |
Material | Stainless Steel 304 |
Material | Stainless Steel;Stainless Steel 304 |
Modification Services | Yes |
Product Family | ProLine |
Size | 173x562x323 |
Thickness | 1.98 mm |
Thickness | 14 ga |
Thickness | 51.40mm (2.024") |
Type | Internal Mounting for ProLine Industrial Enclosures |
Type | Mild Steel Modular Industrial Enclosures |
Weight | 20.72 lb |
Weight | 25 lb |
Width | 22.14 |
Width | 562 |
Width | 562 mm |
Works With | NEMA |
Package Dimensions (L x W x H) | 27.5 IN x 16.5 IN x 8 IN |
Package Dimensions (L x W x H) | 69.85 cm x 41.91 cm x 20.32 cm |
Package Weight (Imperial) | 20.720 L |
Package Weight (Metric) | 9.399 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the PKBS6 Controller
This guide provides step-by-step instructions for installing and configuring the PKBS6 Controller on a DIN rail.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the PKBS6 Controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the power supply
Use terminal connectors to connect the power supply wires to the designated terminals on the PKBS6 Controller. Verify that the connections are secure.
- Configure the controller settings
Power on the PKBS6 Controller and use the interface to navigate to the configuration menu. Set the required parameters according to your application needs.
- Calibrate the controller
Follow the calibration procedure outlined in the manual to ensure accurate readings. Use a multimeter to verify output signals during calibration.
