Overview
- Solenoids are rated for continuous duty and will stand up under heavy industrial use
- Packaged complete with a solenoid assembly, mounting bracket and instructions for field installation
- Door handles and latching mechanisms are not included
- Installation: Interlock mounts on bracket attached to door bar on inside of enclosure door.
- Fits Type 4/12 enclosures, Type 4X with 3-point latches, and HOFFMAN custom designs
Specifications
A @ 220 V/50 Hz Normal Inrush | .060/.35 A |
A @ 220 V/50 Hz Normal Inrush | 0.060 / 0.35 A |
A @ 240 V/60 Hz Normal Inrush | .050/.32 A |
A @ 240 V/60 Hz Normal Inrush | 0.050 / 0.32 A |
Application | Power Distribution; Arc Flash Safety; Controls and Drives |
Application | Arc Flash Safety;Controls and Drives;Power Distribution |
Color | Unpainted |
Finish | Plated |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Product Family | ProLine |
Type | External Mounting for Industrial Enclosures |
Weight | 1 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 5.5 IN x 3 IN x 4 IN |
Package Dimensions (L x W x H) | 13.97 cm x 7.62 cm x 10.16 cm |
Package Weight (Imperial) | 1.000 L |
Package Weight (Metric) | 0.454 kg |
