Contact for Pricing
Overview
- Constructed from durable SS 304 stainless steel for superior corrosion resistance.
- Designed for 1600x600mm PC enclosure frames with left-hand side hinging.
- Features a secure 2-point latch system operated by a tool-access Small Flush Bezel.
- Offers optional latch inserts and a Flush Swing Handle for customizable access.
- Ideal for demanding industrial environments including food/beverage, pharma, and chemical processing.
Specifications
Application | Controls and Drives |
Color | Unpainted |
Finish | Brushed |
Fits PC Frame | 1600 x 600 mm |
Fits PC Frame | 600 wide mm |
Material | Stainless Steel;Stainless Steel 304 |
Material | Stainless Steel 304 |
Modification Services | Yes |
Mounting Type | Hinged (Left Side) |
Product Family | ProLine |
Size | fits 1600x600mm PC in |
Size | 1600x600mm |
Thickness | 1.98 mm |
Thickness | 14 ga |
Thickness | 51.40mm (2.024") |
Type | External Mounting for ProLine Industrial Enclosures |
Type | Stainless Steel |
Weight | 14 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 27.25 IN x 25.75 IN x 3 IN |
Package Dimensions (L x W x H) | 69.215 cm x 65.405 cm x 7.62 cm |
Package Weight (Imperial) | 14.000 L |
Package Weight (Metric) | 6.350 kg |
