nVent PDS228 - Solid Doors, fits 2200x800mm, Painted
nVent

PDS228

UPC: 783510950101

Documents & Media
Installation Instructions

Contact for Pricing

Overview

Enhance the security and environmental protection of your industrial enclosures with the nVent PDS228 Solid Door. Designed to fit 2200x800mm enclosure frames, this robust door is manufactured by nVent, a globally recognized leader in electrical enclosure solutions. The painted finish provides a durable and aesthetically pleasing exterior, suitable for demanding industrial environments. This solid door is engineered for reliability and ease of use. For doors exceeding 700 mm in height or 400 mm in width, a convenient removable door bar system is integrated, ensuring structural integrity and ease of access. The hinge side is reversible, offering maximum flexibility during installation and maintenance. Operation is streamlined via a flush bezel latch that actuates a secure 3-point latching system, providing excellent protection against unauthorized access and environmental ingress. For smaller frames, specifically 700-mm frames, a 2-point latching system is employed, still offering robust security. Installation is simplified by the inclusion of hidden hinges that allow for a 130-degree swing. These hinges can be attached to either the front or back of the enclosure frame, accommodating various layout configurations. Furthermore, the nVent PDS228 can be seamlessly integrated with side-door adapters or cable entry cabinets, enabling attachment to the sides of the enclosure frame. This versatility makes it an ideal solution for complex or space-constrained installations. Key features and benefits include: * **Robust Construction:** Built to withstand harsh industrial conditions. * **Enhanced Security:** 3-point (or 2-point for 700mm frames) latching system with flush bezel operation. * **Installation Flexibility:** Reversible hinge side and hidden hinges with 130-degree swing. * **Adaptable Mounting:** Compatible with side-door adapters and cable entry cabinets for side mounting. * **Durable Finish:** Painted exterior for long-lasting protection and appearance. * **Manufacturer Trust:** From nVent, a trusted name in enclosure systems. This solid door is an essential component for protecting sensitive electrical and electronic equipment in sectors such as manufacturing, power generation, telecommunications, and automation. Its design prioritizes both security and environmental protection, ensuring the longevity and operational efficiency of your critical infrastructure. The 2200x800mm dimensions are standard for many larger industrial enclosures, making the PDS228 a direct replacement or upgrade option. When selecting enclosure doors, consider factors like ingress protection (IP rating), impact resistance, and ease of maintenance. The nVent PDS228 delivers on these fronts, providing a reliable and secure solution for your enclosure needs.
  • EMC doors are finished with paint over plated surfaces
  • Optional data pockets, door stops, grounding kits and 180-degree hinges are available
  • Hinges have easy slide retained hinge pins
  • Door gasket is foam-in-place urethane to provide a resilient, seamless seal
  • Two grounding studs are furnished. All mounting hardware is included

Specifications

Application
Power Distribution; Controls and Drives
Color
Light Gray
Color
Painted
Color Code
RAL 7035
Dimensions
84.21 x 31.18 in
Dimensions
2139 x 792 mm
Door Type
Steel
Fits Frame
2200 x 800 mm
IP Rating
IP55
Material
Mild Steel
Material
Painted Steel
Modification Services
Yes
Mounting Type
Front/Back/Side Mounting
Product Family
ProLine
Series
PDS
Size
fits 2200x800mm
Size
2200x800mm
Thickness
1.9 mm
Thickness
14 ga
Type
External Mounting for ProLine Industrial Enclosures
Weight
79 lb
Package Dimensions (L x W x H)
86.25 IN x 32.75 IN x 2.5 IN
Package Dimensions (L x W x H)
219.075 cm x 83.185 cm x 6.35 cm
Package Weight (Imperial)
79.000 L
Package Weight (Metric)
35.834 kg
Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum

14A0705

Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.

BX4

Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
Escutcheon black type B for Sircover 125-630A

44095015

Escutcheon black type B for Sircover 125-630A
Escutcheon black type B for Sircover 125-630A IP65

44095016

Escutcheon black type B for Sircover 125-630A IP65
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey

LT20D-NEW

1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey

LN43DA

1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black

LH38

Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
EP-RJG-M20-BL-A

1SNG618003R0000

EP-RJG-M20-BL-A
5,90" x 5,90" filter fan - 24Vdc - 20.6 cfm - RAL 9005 - Type 3R - IP55

FF12D24NN53

5,90" x 5,90" filter fan - 24Vdc - 20.6 cfm - RAL 9005 - Type 3R - IP55
12,80" x 12,80" filter fan - 115Vac - 285.3 cfm - RAL 7035 - Type 12

FF20A115UE1

12,80" x 12,80" filter fan - 115Vac - 285.3 cfm - RAL 7035 - Type 12

How to Install the PDWG86 Controller

This guide provides step-by-step instructions for installing and configuring the PDWG86 Controller on a DIN rail.

Estimated time: 45m

Tools needed:

Screwdriver, Wire strippers, Multimeter

Supplies needed:

Mounting screws, Terminal connectors

  1. Mount the controller

    Secure the PDWG86 controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.

  2. Connect the power supply

    Using wire strippers, prepare the power supply wires and connect them to the designated terminals on the controller. Verify the connections are secure.

  3. Configure the controller settings

    Power on the controller and use the interface to set the desired parameters. Follow the on-screen instructions to complete the initial configuration.

  4. Calibrate the controller

    Perform a calibration check by following the calibration procedure outlined in the manual. Use a multimeter to verify output readings.
