Contact for Pricing
Overview
- Seamless foam-in-place gasket assures watertight and dust tight seal
- Semi-flush cover screws attach cover to frame. A ground stud is provided
- Seamless foam-in-place gasket ensures environmental protection
- Designed for 600mm PROLINE-SY lower front PC/SY enclosures
- Includes integrated ground stud and semi-flush cover screws for secure mounting
Specifications
Application | Controls and Drives |
Color | Unpainted |
Depth | 0.69 |
Depth | 18 |
Depth | 18 mm |
Finish | Brushed |
Fits PC Frame | 600 wide mm |
Height | 767 mm |
Height | 30.2 |
Height | 767 |
Material | Stainless Steel 304 |
Material | Stainless Steel;Stainless Steel 304 |
Modification Services | Yes |
Product Family | ProLine |
Size | fits 600mm PC/SY in |
Thickness | 1.98 mm |
Thickness | 14 ga |
Thickness | 51.40mm (2.024") |
Type | Mild Steel Modular Industrial Enclosures |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 15 lb |
Width | 592 mm |
Width | 23.31 |
Width | 592 |
Works With | NEMA |
Package Dimensions (L x W x H) | 33.25 IN x 27.5 IN x 1 IN |
Package Dimensions (L x W x H) | 84.455 cm x 69.85 cm x 2.54 cm |
Package Weight (Imperial) | 15.000 L |
Package Weight (Metric) | 6.804 kg |
