Contact for Pricing
Overview
- EMC covers are finished with paint over plated surfaces
- 14-gauge mild steel construction for widths >600mm
- Seamless polyurethane gasket for watertight, dust-tight seal
- Formed steel hems for structural support and safety
- Includes two grounding studs and all mounting hardware
Specifications
Application | Controls and Drives; Power Distribution |
Color | Light Gray |
Color | Painted |
Color Code | RAL 7035 |
Cover Style | Steel |
Dimensions | 1139 x 792 mm |
Dimensions | 44.84 x 31.18 in |
Fits Frame | 1200 x 800 mm |
IP Rating | IP55 |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Mounting Type | Semi-flush screw mounting |
Product Family | ProLine |
Series | ProLine |
Size | 1200x800mm |
Size | 47.24 x 31.5 in |
Thickness | 1.9 mm |
Thickness | 14 ga |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 41 lb |
Package Dimensions (L x W x H) | 49 IN x 32 IN x 5 IN |
Package Dimensions (L x W x H) | 124.46 cm x 81.28 cm x 12.7 cm |
Package Weight (Imperial) | 41.000 L |
Package Weight (Metric) | 18.598 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
How to Install the PCS86 Controller
This guide provides step-by-step instructions for installing and configuring the PCS86 Controller on a DIN rail.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the PCS86 Controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the power supply
Using terminal connectors, connect the power supply wires to the designated terminals on the PCS86 Controller. Ensure proper polarity is observed.
- Verify connections
Use a multimeter to check the voltage at the power terminals of the PCS86 Controller. Confirm that the voltage matches the specifications outlined in the documentation.
Frequently Asked Questions about nVent
What industries and applications are nVent products used for?
nVent products are engineered for critical infrastructure and industrial applications across multiple demanding sectors. Key markets include Construction, Data Centers, Defense, Healthcare, Mining, Oil & Gas Refineries, Power Plants, Rail/Transit, Renewable Energy, Security, Ship Building, Steel Mills, Telecom, and Utilities. Their solutions are designed to withstand extreme environmental conditions, with temperature ranges from -55°C to 105°C and specialized features like UV resistance, oil resistance, and flame resistance.
What environmental ratings do nVent products have?
nVent enclosures feature comprehensive environmental ratings, including UL 508A, CSA, and NEMA Type 1, 2, 3, 4, 4X, 12, and 13 certifications. They are rated IEC 60529 IP66, providing robust protection against dust, water, and corrosion in both indoor and outdoor environments. These products operate effectively in temperatures ranging from -40°F to 266°F, with enhanced UV inhibitors for outdoor weathering and oil-resistant gaskets for superior sealing.
What accessories are available for nVent products?
nVent offers a comprehensive range of accessories across multiple product lines, including EMC accessories like bonding cable clamps and strain reliefs, inline accessories such as lock inserts and mounting brackets, CONCEPT accessories including panel conversion kits and rack-mount angles, and seismic accessories for specialized mounting requirements. Key accessory categories include grounding kits, DIN rail mounting solutions, panel supports, handles, and various mounting hardware compatible with different enclosure types.
What certifications and standards do nVent products comply with?
nVent products meet critical international certifications including UL (United States), CSA (Canada), CE (European Community), and EAC (Russia). Our products are designed to comply with rigorous industrial standards such as NEMA enclosure ratings, IEC 60529 IP ratings, and international safety standards across multiple industrial markets including oil & gas, power, manufacturing, and infrastructure.
What is nVent's warranty policy?
nVent offers a standard 18-month warranty from invoicing date for most automation products, covering defects in workmanship and materials. The warranty requires proper transportation, handling, storage, and installation within specified environmental conditions. Warranty coverage includes repair or replacement at nVent's discretion, with certain conditions such as authorized service repairs and operation within designed capacity limits.
What technical support does nVent offer?
nVent offers comprehensive technical support through multiple global contact centers across North America, South America, Europe, Middle East, India, and Asia. Customers can reach technical experts by phone at regional numbers, with the North American headquarters in Minneapolis, MN providing primary support at +1.763.421.2240. Additionally, nVent provides online support resources through their website, including CAD drawing downloads and an 'Ask The Expert' feature to assist with product technical inquiries.
