Overview
- Reversible design
- Screw cover on the flat side has foam in place gasket
- Ground stud and mounting hardware included.
- Open rear surface gasket extends NEMA 4X and IP66 ingress protection
- Designed for 800mm frame width, includes ground stud and mounting hardware
Specifications
Application | Controls and Drives |
Color | Unpainted |
Color | Brushed |
Depth | 324 mm |
Depth | 12.75 |
Depth | 324 |
Finish | Brushed |
Fits Frame Width | 800 mm |
Fits Frame Width | 600 mm |
Height | 175 mm |
Height | 6.89 |
Height | 175 |
Material | SS304 |
Material | Stainless Steel 304 |
Material | Stainless Steel;Stainless Steel 304 |
Modification Services | Yes |
Mounting Type | Reversible design with 20-degree angled surface |
Product Family | ProLine |
Series | PROLINE-PC |
Size | fits 800mm PC/SY in |
Size | 800mm |
Thickness | 1.98 mm |
Thickness | 14 ga |
Thickness | 51.40mm (2.024") |
Type | Internal Mounting for ProLine Industrial Enclosures |
Type | Mild Steel Modular Industrial Enclosures |
Weight | 29 lb |
Weight | 29.1 lb |
Width | 31.17 |
Width | 792 |
Width | 792 mm |
Works With | NEMA |
Package Dimensions (L x W x H) | 34.25 IN x 17 IN x 29.1 IN |
Package Dimensions (L x W x H) | 86.995 cm x 43.18 cm x 73.914 cm |
Package Weight (Imperial) | 29.100 L |
Package Weight (Metric) | 13.200 kg |
