Contact for Pricing
Overview
- Solution includes frame, width and depth mounted covers, gaskets for sealing junction between top of frame and module, and all installation hardware to secure to the top of a G2 frame
- Solid Top sold separately, but also included with standard Industrial Package
- 200mm and 300mm heights available
- Includes single ground stud per cover
- Painted finish for durability in industrial environments
Specifications
Application | Power Distribution; Controls and Drives |
Cable Entry | No |
Color | Light Gray |
Color Code | RAL 7035 |
Finish | Powder Coated |
Fits Frame | 600 x 500 mm |
Fits Frame | 23.62 x 19.69 in |
Fits Frame Type | Single Bay |
Insulation | No |
Material | Mild Steel |
NEMA Rating | 12 |
Product Family | ProLine |
Size | 7.84 x 33.62 x 19.69 |
Thickness | 16 ga |
Thickness | 1.5 mm |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 38.65 lb |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
