Contact for Pricing
Overview
- Solution includes frame, width and depth mounted covers, gaskets for sealing junction between top of frame and module, and all installation hardware to secure to the top of a G2 frame
- Solid Top sold separately, but also included with standard Industrial Package
- 200mm and 300mm heights available
- Includes single ground stud per cover
- Joinable design supports multi-bay solutions and system expansion.
Specifications
Application | Power Distribution; Controls and Drives |
Cable Entry | No |
Color | Light Gray |
Color Code | RAL 7035 |
Finish | Powder Coated |
Fits Frame | 1600 x 600 mm |
Fits Frame | 63.00 x 23.62 in |
Fits Frame Type | Double Bay |
Insulation | No |
Material | Mild Steel |
NEMA Rating | 12 |
Product Family | ProLine |
Size | 7.84 x 62.99 x 23.62 |
Thickness | 16 ga |
Thickness | 1.5 mm |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 78.59 lb |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
How to Install the P2TMM2166 Controller
This guide provides step-by-step instructions for installing and configuring the P2TMM2166 Controller, ensuring proper wiring and setup.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the P2TMM2166 controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the power supply
Using wire connectors, connect the power supply wires to the designated terminals on the controller. Ensure the connections are tight and secure to prevent any electrical issues.
- Verify connections
Use a multimeter to check the voltage at the power terminals to ensure proper power supply. The voltage should match the specifications outlined in the controller documentation.
- Configure the controller settings
Access the controller's configuration interface and input the necessary parameters as per your application requirements. Follow the on-screen instructions to complete the setup.
- Calibrate the controller
Perform a calibration procedure as specified in the documentation to ensure accurate readings and functionality. Follow the calibration steps carefully.
