Overview
- Rack Frame horizontal members are 10-gauge (3.0mm), while vertical members are 12-gauge (2.5 mm)
- All mounting hardware included for installation into 800mm wide enclosures
- Depth adjustability up to 190mm (7.5 in.) has also been built into the solution to accommodate equipment that extends forward beyond the rack frame
- Left justified is the only standard configuration, and the minimum frame width must be 800mm to allow the rack frame to fully swing out of the enclosure
- Filler panel with handle is included standard to occupy the space adjacent to the rack frame.
- Load capacity of 300lb (136kg).
- Compatible with standard 19-inch rack accessories
- Meets EIA-310-D rack mounting standards
Specifications
Application | Controls and Drives; Power Distribution |
Color | Jet Black |
Color | Black |
Color Code | RAL 9005 |
Finish | Powder Coated |
Fits Frame | 86.61 x 31.50 in |
Fits Frame | 2200 x 800 mm |
Load Rating | 300 lb |
Load Rating | 136 kg |
Material | Steel |
Material | Mild Steel |
Mounting Type | Floor-standing with casters/levelers |
Mounting Type | Floor-standing |
Product Family | ProLine |
Series | ProLine G2 |
Size | 2200x800 mm |
Thickness | 3.4 mm |
Thickness | 10 ga |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 180 lb |
