Overview
- 12-gauge (2.5 mm) roll-formed steel with welded corners, and hybrid frame profile for superior performance under load
- Frame features a 25-mm DIN standard, alternating rectangular and round hole pattern
- Enclosures with a width of 1200mm or less have a single-piece rear cover, and can accommodate a fully-recessed mounting subpanel; enclosures with a width of greater than 1200mm have two rear covers that affix to a removable center upright/vertical combina
- Gasket is seamless polyurethane providing a water-tight, dust-tight seal against moisture and contaminants; UL component recognized, CSA compliant
- Door bar system present on all doors (including window doors)
- Single/primary door includes Smooth Glide Latching System, 3-point roller latch system with timed latch engagement, for enclosures greater than or equal to 1000 mm in height; system ensures a solid and repeatable seal with a low closure force
- 2-door enclosures include overlapping double doors to provide full-width open front, with a secondary door that latches with two levers
- Reversible hinging on single doors (default left hinge), and on overlapping double doors (default right door primary door)
- Two grounding studs present on each door
- Low-Profile Flush Swing Handle with key lock on standard versions; double bit lock on 'E' versions; other handle options available (sold separately)
Specifications
Application | Power Distribution; Controls and Drives |
Color | Light Gray |
Color | Lt Gray |
Color Code | RAL 7035 |
Depth | 19.7 |
Depth | 505 |
Door Quantity | 2 |
Finish | Powder Coated |
Height | 86.69 |
Height | 2,202 |
Material | Mild Steel |
Material | Steel |
Max Rack Mount Unit | 47 |
Max Subpanel Size | 2106 x 928 mm |
Max Subpanel Size | 82.9 x 36.5 in |
Nema Rating | Type 12 |
Product Family | ProLine |
Series | ProLine G2 Industrial Packages |
Size | 2200x1000x500 |
Type | Mild Steel Modular Industrial Enclosures |
Width | 39.67 |
Width | 1,008 |
