Overview
- Quick installation of grid strap(s) using the patented front-load BV-M6 fastener (Blind, Variable M6 screw based fastener), which is an innovative alternative to cage nuts or self-tapping screws
- Mounting hole pattern is 25-mm on center, alternating round and rectangular holes to accommodate various hardware: rectangular holes accept BV-M6 fasteners or front-loading cage nuts
- Horizontal grid straps are offered in both 1-row and 3-row configurations, as well as bracket or tabbed (single-piece) mounting options
- Width-mounting Grid Straps requires an increase in length of 100mm over the nominal frame width (i.e. 600mm wide enclosure requires 700mm grid strap)
- Horizontal, Bracket-Mount Grid Straps: Mounting brackets are installed using a single BV-M6 (or front-loading cage nut) per bracket. Grid Strap hooks onto the mounted brackets, and snaps into place for easy installation; this design Grid Strap can be moun
- Horizontal, Tab-Mount, Single-Piece Grid Straps: Grid Strap is constructed from a single piece, with a jogged tab that allows the Grid Strap to sit flush with the frame; this design Grid Strap should not be used when mounting vertically between other Grid
- Furnished in pairs, and constructed from 14 gauge (1.75mm) conductive steel
Specifications
Application | Controls and Drives; Power Distribution |
Color | Unpainted |
Finish | Galvanized |
Fits Frame Width | 800 mm |
Material | Steel |
Material | Mild Steel |
Mounting Type | Tab-mount |
Product Family | ProLine |
Series | ProLine G2 |
Size | 900mm |
Thickness | 14 ga |
Thickness | 1.9 mm |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 5.02 lb |
Package Dimensions (L x W x H) | 39.13 IN x 5.5 IN x 5 IN |
Package Dimensions (L x W x H) | 99.3902 cm x 13.97 cm x 12.7 cm |
Package Weight (Imperial) | 5.020 L |
Package Weight (Metric) | 2.277 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
How to Install the P2GV3R8 Controller
This guide provides step-by-step instructions for installing and configuring the P2GV3R8 Controller.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the P2GV3R8 controller to the designated mounting surface using the provided mounting screws. Ensure it is level and securely fastened.
- Connect the power supply
Using wire strippers, prepare the power supply wires and connect them to the power terminals on the controller. Ensure correct polarity and secure the connections.
- Verify connections
Use a multimeter to check the voltage at the power terminals to ensure proper power supply. Confirm that the readings match the specifications outlined in the controller manual.
