nVent P2F1885 - ProLine G2 Frames, 1800x800x500
nVent

P2F1885

UPC: 783510317362

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent ProLine G2 Frame (SKU: P2F1885) represents the robust and reliable foundation for your critical electrical and electronic equipment. As the core structural element of the ProLine G2 modular enclosure system, this frame is engineered to provide unparalleled support and protection for sensitive components. Designed with demanding industrial environments in mind, the ProLine G2 frame boasts exceptional load-bearing capabilities and maintains a consistently square and rigid structure, ensuring the integrity of your enclosure even under significant stress. This frame is not merely a structural component; it is the bedrock upon which your entire enclosure solution is built. Its meticulous design prioritizes stability, ensuring that internal equipment remains secure and shielded from external factors. The substantial dimensions of 1800mm (height) x 800mm (width) x 500mm (depth) offer ample space for a wide array of electrical configurations, control systems, and IT infrastructure. Whether you are deploying solutions in manufacturing plants, data centers, utility substations, or telecommunications facilities, the ProLine G2 frame provides the dependable base required for optimal performance and longevity. The nVent ProLine G2 frame is manufactured in the USA, reflecting a commitment to quality and precision engineering. This origin signifies adherence to stringent manufacturing standards and a dedication to producing durable, high-performance products. The modular nature of the ProLine G2 system, with this frame at its heart, allows for flexible configurations and scalability, adapting to evolving project requirements. Professionals choose nVent for their enclosure solutions due to the brand's reputation for innovation, reliability, and comprehensive product offerings that meet the rigorous demands of modern industry. Key benefits and features of the nVent ProLine G2 Frame include: * **Superior Structural Integrity:** Engineered to withstand heavy load requirements, ensuring the safety and stability of enclosed equipment. * **Solid Square Construction:** Maintains a rigid and precise form factor, crucial for the proper mounting and alignment of internal components. * **Modular System Foundation:** Serves as the primary building block for the versatile ProLine G2 modular enclosure system, allowing for customized configurations. * **Ample Internal Space:** Generous dimensions (1800x800x500mm) accommodate a wide range of electrical, control, and IT equipment. * **Designed for Harsh Environments:** Built to endure the challenges of industrial settings, providing reliable protection for critical assets. * **USA Manufacturing:** Produced in the United States, assuring high quality and adherence to strict manufacturing standards. When selecting an enclosure solution, the frame is a critical consideration. The nVent ProLine G2 frame offers peace of mind, knowing that your valuable equipment is housed within a structure built for endurance and performance. Its robust design minimizes the risk of structural failure, vibration damage, and misalignment, contributing to reduced downtime and maintenance costs. Invest in a foundation that supports your operational continuity and protects your critical infrastructure with the nVent ProLine G2 Frame.
  • 12 gauge (2.5mm), roll-formed steel frame with welded steel corners and hybrid frame profile for superior performance under load
  • RAL 7035 textured light-gray polyester powder paint finish
  • Frame features a 25-mm DIN standard, alternating rectangular and round hole pattern
  • Flange trough collar on door and side openings deflect dust and debris away from the enclosure interior
  • Removable rear center vertical/support for frames greater than 1200-mm in width; there is no front center vertical, providing full access for subpanel installation
  • Integral frame channels support the full weight of the mounting subpanel, which comes with the EZ Load Glide Block system for multiple subpanel installation methods
  • Individual frames designed for joining/baying in multiple directions with the inclusion of joining kits
  • Provisions for mounting subpanel, rack mounting and grid/rail system mounting to support many unique customer applications
  • Appropriate gasketed door(s) and covers are required to maintain a Type-12 environmental rating, sold separately
  • Accommodates 25-mm DIN standard; rectangular frame holes designed for BV-M6 fastener or metric cage nut fasteners; round frame holes accommodate M5 self-tapping screws and allow numerous grounding locations using M5 thread-forming screws

Specifications

Application
Controls and Drives; Power Distribution
Color
Light Gray
Color Code
RAL 7035
Finish
Powder Coated
Material
Mild Steel
Max Rack Mount Unit
38
Max Subpanel Size
1706 x 728 mm
Max Subpanel Size
67.2 x 28.7 in
Product Family
ProLine
Thickness
12 ga
Thickness
2.66 mm
Type
Internal Mounting for ProLine Industrial Enclosures
Weight
60 lb
Package Dimensions (L x W x H)
37 IN x 26 IN x 76 IN
Package Dimensions (L x W x H)
93.98 cm x 66.04 cm x 193.04 cm
Package Weight (Imperial)
60.000 L
Package Weight (Metric)
27.216 kg
Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum

14A0705

Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.

BX4

Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black

LH38

Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
EP-RJG-M20-BL-A

1SNG618003R0000

EP-RJG-M20-BL-A
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey

LN43DA

1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey

LT20D-NEW

1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
Escutcheon black type B for Sircover 125-630A

44095015

Escutcheon black type B for Sircover 125-630A
Escutcheon black type B for Sircover 125-630A IP65

44095016

Escutcheon black type B for Sircover 125-630A IP65
12,80" x 12,80" filter fan - 115Vac - 285.3 cfm - RAL 7035 - Type 12

FF20A115UE1

12,80" x 12,80" filter fan - 115Vac - 285.3 cfm - RAL 7035 - Type 12
5,90" x 5,90" filter fan - 24Vdc - 20.6 cfm - RAL 9005 - Type 3R - IP55

FF12D24NN53

5,90" x 5,90" filter fan - 24Vdc - 20.6 cfm - RAL 9005 - Type 3R - IP55

How to Install the PF1885 Enclosure

This guide provides step-by-step instructions for safely installing the PF1885 enclosure, ensuring proper handling and setup.

Estimated time: 1h

Tools needed:

Forklift, Screwdriver, Multimeter

Supplies needed:

3000 lb-rated chain or strap, Mounting screws

  1. Prepare the installation area

    Clear the installation route of all obstructions and ensure that workers are positioned at a safe distance from the enclosure's height.

  2. Secure the enclosure for transport

    Using a forklift, insert a 3000 lb-rated chain or strap through the eye bolts on top of the enclosure and securely fasten it to the forklift mast to prevent tipping during transport.

  3. Lift and position the enclosure

    Carefully lift the enclosure with the forklift, ensuring it is clear of the ground. Position it at the designated installation site, maintaining caution to avoid contact with fixed objects.

  4. Mount the enclosure

    Secure the enclosure to the mounting surface using the provided mounting screws, ensuring it is level and firmly attached.

  5. Verify installation

    Check that the enclosure is stable and securely mounted. Use a multimeter to verify any electrical connections if applicable.
