Overview
- Hinge hanger on top for easy alignment
- Formed steel hems on the sides of the covers for enhanced structural support and to protect user from sharp edges
- Seamless polyurethane gasket (UL component recognized) provides a water-tight, dust-tight seal against moisture and contaminants
- Attach to enclosure frame with low-profile, flat head screws
- Door can be reversed without removing the side covers
- Used on the sides of the ProLine G2 frame
- Not suitable as a barrier between enclosures (instead use the ProLine G2 barrier panel)
- Two grounding studs
- All mounting hardware included
- Side Covers are finished with paint over plated surfaces
Specifications
Application | Controls and Drives; Power Distribution |
Color | Light Gray |
Color Code | RAL 7035 |
Depth | 0.79 |
Depth | 20 |
Finish | Powder Coated |
Fits Frame Height | 2000 x 600 mm |
Height | 78.1 |
Height | 1,983 |
Material | Mild Steel |
Product Family | ProLine |
Thickness | 16 ga |
Thickness | 1.52 mm |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 40 lb |
Width | 22.2 |
Width | 564 |
Package Dimensions (L x W x H) | 82.75 IN x 26.75 IN x 2 IN |
Package Dimensions (L x W x H) | 210.185 cm x 67.945 cm x 5.08 cm |
Package Weight (Imperial) | 40.000 L |
Package Weight (Metric) | 18.144 kg |
