Contact for Pricing
Overview
- Conductive finish
- Set of 2 brackets
- Mounting hardware included; attaches to frame using BV-M6 fastener, and subpanel using metric hex bolts
- Mounting hardware included
- Galvanized steel
Specifications
Application | Power Distribution; Controls and Drives |
Color | Unpainted |
Depth | 1.57 |
Depth | 40 |
Finish | Galvanized |
Height | 1.77 |
Height | 45 |
Material | Mild Steel |
Product Family | ProLine |
Thickness | 3.04 mm |
Thickness | 11 ga |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 0.6 lb |
Width | 1.97 |
Width | 50 |
Package Dimensions (L x W x H) | 10.75 IN x 9.5 IN x 1.75 IN |
Package Dimensions (L x W x H) | 27.305 cm x 24.13 cm x 4.445 cm |
Package Weight (Imperial) | 0.600 L |
Package Weight (Metric) | 0.272 kg |
