Overview
- Solution based around a ½-in (13 mm) Aluminum Hex Rod
- Consult installation instructions to determine which components would be required to safely interlock a defined solution.
- Master door can be positioned anywhere; slave doors lock until master is closed
- Modular design with pre-engineered brackets, rods, and fasteners for quick assembly
- Compliant with OSHA and NFPA 79 safety standards
Specifications
Application | Controls and Drives; Power Distribution |
Color | Unpainted |
Finish | Plated |
Material | Aluminum |
Material | Mild Steel |
Mounting Type | Top-mounted actuator |
Product Family | ProLine |
Series | ProLine G2 |
Series | ProLine G2 Mechanical Interlock |
Size | ½-in (13 mm) |
Size | ½-inch (13 mm) hex rod |
Type | Extension Kit, Long |
Weight | 2.87 lb |
Package Dimensions (L x W x H) | 86.25 IN x 5.5 IN x 4.9 IN |
Package Dimensions (L x W x H) | 219.075 cm x 13.97 cm x 12.446 cm |
Package Weight (Imperial) | 2.870 L |
Package Weight (Metric) | 1.302 kg |
