nVent P2AIBP85 - ProLine G2 Internal Barrier Panel, 800x500, Steel, Light Gray
nVent

P2AIBP85

UPC: 783510364274

Documents & Media
Installation Instructions

Contact for Pricing

Overview

Enhance your enclosure's internal organization and safety with the nVent ProLine G2 Internal Barrier Panel (SKU: P2AIBP85). Designed for robust industrial applications, this panel offers a practical solution for segmenting larger enclosures into distinct operational zones. Its primary function is to mount horizontally within an enclosure, much like a frame shelf, effectively dividing the vertical space into multiple bays. This capability is particularly valuable in configurations utilizing partial door enclosures, where precise internal compartmentalization is essential for managing different systems or components. The ProLine G2 Internal Barrier Panel is constructed from high-quality steel, ensuring durability and resistance to the demanding environments often found in manufacturing, automation, and data center facilities. The light gray finish provides a clean, professional aesthetic that complements most industrial enclosure designs. With dimensions of 800x500mm, this panel is engineered to fit seamlessly within compatible nVent ProLine G2 enclosures, offering a precise and secure installation. Key benefits of integrating the nVent ProLine G2 Internal Barrier Panel include: * **Improved Organization:** Create distinct compartments for electrical, electronic, or mechanical equipment, preventing interference and simplifying maintenance. * **Enhanced Safety:** Separate high-voltage components from sensitive electronics or personnel access areas, reducing risks. * **System Segmentation:** Ideal for modular system designs, allowing for independent access and management of different enclosure sections. * **Partial Door Solutions:** Facilitates the creation of multi-zone enclosures where only specific sections require door access. * **Durable Construction:** Made from robust steel for long-term reliability in harsh industrial settings. When selecting internal partitioning solutions, professionals prioritize products that offer both structural integrity and ease of integration. The nVent ProLine G2 series is renowned for its engineering excellence and commitment to providing reliable enclosure accessories. This internal barrier panel is a testament to that, offering a straightforward installation process that minimizes downtime. Whether you are deploying complex automation systems, critical power distribution units, or advanced networking infrastructure, the nVent ProLine G2 Internal Barrier Panel provides the foundational structure for a well-managed and secure enclosure environment. Its application extends across various industries, including automotive manufacturing, food and beverage processing, telecommunications, and renewable energy, where reliable and organized electrical enclosures are paramount. Trust nVent to deliver solutions that meet the stringent demands of modern industrial operations.
  • Barrier and extender panels are 16 gauge (1.5 mm), while mounting brackets are 14 gauge (1.75 mm)
  • RAL 7035 polyester powder paint, textured light gray
  • All mounting hardware included
  • Durable steel construction for industrial environments
  • 800x500mm size, light gray finish

Specifications

Application
Controls and Drives; Power Distribution
Cable Entry
No
Color
Light Gray
Color Code
RAL 7035
Finish
Powder Coated
Fits Frame
800 x 500 mm
Insulation
No
Material
Mild Steel
Product Family
ProLine
Thickness
16 ga
Thickness
1.52 mm
Type
Internal Mounting for ProLine Industrial Enclosures
Weight
27.64 lb
Package Dimensions (L x W x H)
41 IN x 18 IN x 1.88 IN
Package Dimensions (L x W x H)
104.14 cm x 45.72 cm x 4.7752 cm
Package Weight (Imperial)
27.640 L
Package Weight (Metric)
12.538 kg
