Overview
- Barrier and extender panels are 16 gauge (1.5 mm), while mounting brackets are 14 gauge (1.75 mm)
- RAL 7035 polyester powder paint, textured light gray
- All mounting hardware included
- Designed for horizontal plane mounting for secure installation.
- Ideal for creating separate bays within electrical enclosures.
Specifications
Application | Controls and Drives; Power Distribution |
Cable Entry | No |
Color | Light Gray |
Color Code | RAL 7035 |
Finish | Powder Coated |
Fits Frame | 800 x 400 mm |
Insulation | No |
Material | Mild Steel |
Product Family | ProLine |
Thickness | 16 ga |
Thickness | 1.52 mm |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 21.36 lb |
Package Dimensions (L x W x H) | 38 IN x 14 IN x 1.88 IN |
Package Dimensions (L x W x H) | 96.52 cm x 35.56 cm x 4.7752 cm |
Package Weight (Imperial) | 21.360 L |
Package Weight (Metric) | 9.689 kg |
