nVent P24RP8UP - ProLine Rack Panel EIA Spacing 8U, 355x610x2.5mm, Light Gray, Mild Steel
nVent

P24RP8UP

UPC: 783510767006

Contact for Pricing

Overview

The nVent ProLine Rack Panel (SKU: P24RP8UP) is a robust 8U (8.75-inch) panel designed for 19-inch EIA-compliant racks. Constructed from 12-gauge mild steel, it features a durable RAL 7035 textured light gray polyester powder paint finish. Its dimensions are 355mm x 610mm x 2.5mm, providing substantial rigidity to prevent flex, even with heavier mounted components. This panel is ideal for organizing equipment, managing airflow, and protecting against dust in various environments. The oblong mounting holes are precisely positioned at EIA standard spacing, ensuring universal compatibility with standard rack systems. Applications include data centers, enterprise server rooms, industrial automation facilities, telecom hubs, and broadcast studios. It can be used to mount monitors, keyboards, or small enclosures, or function as a blanking plate to optimize airflow and cable management. Mounting hardware is sold separately; consider the nVent ECNSM6 fastener package kit for tool-free installation. Meets ANSI/EIA-310-E standards for rack organization and management.
  • Available in aluminum or painted steel; steel is RAL 7035 textured light-gray polyester powder paint
  • Aluminum panels are 0.125-in. thick 5052-H32 alloy; steel panels are 12 gauge
  • All panels are flat with oblong holes positioned at EIA standard spacing (rack units)
  • Mounting hardware sold separately; recommend use of ECNSM6
  • Dimensions: 355mm x 610mm x 2.5mm

Specifications

Application
Controls and Drives
Color
Light Gray
Color Code
RAL 7035
Finish
Powder Coated
Material
Mild Steel
Modification Services
Yes
Mounting Type
EIA Spacing, 19-inch rack-mountable
Product Family
ProLine
Rack Angle Size
24 in.
Rack Units
8
Series
nVent ProLine
Size
8Ux 24.00 in
Size
355x610x2.5mm
Thickness
2.66 mm
Thickness
12
Type
Internal Mounting for ProLine Industrial Enclosures
Weight
10.2 lb
Package Dimensions (L x W x H)
24.5 IN x 17 IN x 0.25 IN
Package Dimensions (L x W x H)
62.23 cm x 43.18 cm x 0.635 cm
Package Weight (Imperial)
10.200 L
Package Weight (Metric)
4.627 kg
